ns3::ExtendedSupportedRatesIE Class Reference
The Extended Supported Rates Information Element. More...
#include <supported-rates.h>
Public Member Functions | |
| ExtendedSupportedRatesIE (SupportedRates *rates) | |
| WifiInformationElementId | ElementId () const |
| Own unique Element ID. | |
| uint8_t | GetInformationFieldSize () const |
| void | SerializeInformationField (Buffer::Iterator start) const |
| uint8_t | DeserializeInformationField (Buffer::Iterator start, uint8_t length) |
| Buffer::Iterator | Serialize (Buffer::Iterator start) const |
| Serialize entire IE including Element ID and length fields. | |
| uint16_t | GetSerializedSize () const |
Detailed Description
The Extended Supported Rates Information Element.
This class knows how to serialise and deserialise the Extended Supported Rates Element that holds (non-HT) rates beyond the 8 that the original Supported Rates element can carry.
The SupportedRates class still records all the rates, and an instance of ExtendedSupportedRatesIE lies within SupportedRates.
Member Function Documentation
| uint8_t ns3::ExtendedSupportedRatesIE::DeserializeInformationField | ( | Buffer::Iterator | start, | |
| uint8_t | length | |||
| ) | [virtual] |
Deserialize information (i.e., the body of the IE, not including the Element ID and length octets)
Implements ns3::WifiInformationElement.
| uint8_t ns3::ExtendedSupportedRatesIE::GetInformationFieldSize | ( | ) | const [virtual] |
Length of serialized information (i.e., the length of the body of the IE, not including the Element ID and length octets. This is the value that will appear in the second octet of the entire IE - the length field)
Implements ns3::WifiInformationElement.
| uint16_t ns3::ExtendedSupportedRatesIE::GetSerializedSize | ( | ) | const |
Get the size of the serialized IE including Element ID and length fields.
Reimplemented from ns3::WifiInformationElement.
| void ns3::ExtendedSupportedRatesIE::SerializeInformationField | ( | Buffer::Iterator | start | ) | const [virtual] |
Serialize information (i.e., the body of the IE, not including the Element ID and length octets)
Implements ns3::WifiInformationElement.
The documentation for this class was generated from the following file:
- src/devices/wifi/supported-rates.h
