ns3::dsdv::RoutingTable Class Reference
[Dsdv]
The Routing table used by DSDV protocol. More...
#include <dsdv-rtable.h>
Public Member Functions | |
| bool | AddRoute (RoutingTableEntry &r) |
| bool | DeleteRoute (Ipv4Address dst) |
| bool | LookupRoute (Ipv4Address dst, RoutingTableEntry &rt) |
| bool | LookupRoute (Ipv4Address id, RoutingTableEntry &rt, bool forRouteInput) |
| bool | Update (RoutingTableEntry &rt) |
| void | GetListOfDestinationWithNextHop (Ipv4Address nxtHp, std::map< Ipv4Address, RoutingTableEntry > &dstList) |
| void | GetListOfAllRoutes (std::map< Ipv4Address, RoutingTableEntry > &allRoutes) |
| void | DeleteAllRoutesFromInterface (Ipv4InterfaceAddress iface) |
| void | Clear () |
| void | Purge (std::map< Ipv4Address, RoutingTableEntry > &removedAddresses) |
| void | Print (Ptr< OutputStreamWrapper > stream) const |
| uint32_t | RoutingTableSize () |
| bool | AddIpv4Event (Ipv4Address, EventId) |
| bool | DeleteIpv4Event (Ipv4Address address) |
| bool | AnyRunningEvent (Ipv4Address address) |
| bool | ForceDeleteIpv4Event (Ipv4Address address) |
| EventId | GetEventId (Ipv4Address address) |
|
| |
| Time | Getholddowntime () const |
| void | Setholddowntime (Time t) |
Detailed Description
The Routing table used by DSDV protocol.
Member Function Documentation
| bool ns3::dsdv::RoutingTable::AddIpv4Event | ( | Ipv4Address | , | |
| EventId | ||||
| ) |
Add an event for a destination address so that the update to for that destination is sent after the event is completed.
- Parameters:
-
destination address for which this event is running. unique eventid that was generated.
| bool ns3::dsdv::RoutingTable::AddRoute | ( | RoutingTableEntry & | r | ) |
Add routing table entry if it doesn't yet exist in routing table
- Parameters:
-
r routing table entry
- Returns:
- true in success
| bool ns3::dsdv::RoutingTable::AnyRunningEvent | ( | Ipv4Address | address | ) |
Force delete an update waiting for settling time to complete as a better update to same destination was received.
- Parameters:
-
destination address for which this event is running.
- Returns:
- true on success
| bool ns3::dsdv::RoutingTable::DeleteIpv4Event | ( | Ipv4Address | address | ) |
Clear up the entry from the map after the event is completed
- Parameters:
-
destination address for which this event is running.
- Returns:
- true on success
| bool ns3::dsdv::RoutingTable::DeleteRoute | ( | Ipv4Address | dst | ) |
Delete routing table entry with destination address dst, if it exists.
- Parameters:
-
dst destination address
- Returns:
- true on success
| bool ns3::dsdv::RoutingTable::ForceDeleteIpv4Event | ( | Ipv4Address | address | ) |
Force delete an update waiting for settling time to complete as a better update to same destination was received.
- Parameters:
-
destination address for which this event is running.
- Returns:
- true on finding out that an event is already running for that destination address.
| EventId ns3::dsdv::RoutingTable::GetEventId | ( | Ipv4Address | address | ) |
Get the EcentId associated with that address.
- Parameters:
-
destination address for which this event is running.
- Returns:
- EventId on finding out an event is associated else return NULL.
| void ns3::dsdv::RoutingTable::GetListOfAllRoutes | ( | std::map< Ipv4Address, RoutingTableEntry > & | allRoutes | ) |
Lookup list of all addresses in the routing table
- Parameters:
-
allRoutes is the list that will hold all these addresses present in the nodes routing table
| void ns3::dsdv::RoutingTable::GetListOfDestinationWithNextHop | ( | Ipv4Address | nxtHp, | |
| std::map< Ipv4Address, RoutingTableEntry > & | dstList | |||
| ) |
Lookup list of addresses for which nxtHp is the next Hop address
- Parameters:
-
nexthop's address for which we want the list of destinations dstList is the list that will hold all these destination addresses
| bool ns3::dsdv::RoutingTable::LookupRoute | ( | Ipv4Address | dst, | |
| RoutingTableEntry & | rt | |||
| ) |
Lookup routing table entry with destination address dst
- Parameters:
-
dst destination address rt entry with destination address dst, if exists
- Returns:
- true on success
| bool ns3::dsdv::RoutingTable::Update | ( | RoutingTableEntry & | rt | ) |
Updating the routing Table with routing table entry rt
- Parameters:
-
routing table entry rt
- Returns:
- true on success
The documentation for this class was generated from the following file:
- src/routing/dsdv/model/dsdv-rtable.h
