Public Member Functions |
| ArfWifiManager () |
virtual | ~ArfWifiManager () |
| WifiRemoteStationManager () |
virtual | ~WifiRemoteStationManager () |
void | AddBasicMode (WifiMode mode) |
void | AddSupportedMode (Mac48Address address, WifiMode mode) |
WifiMode | GetAckMode (Mac48Address address, WifiMode dataMode) |
WifiMode | GetBasicMode (uint32_t i) const |
WifiMode | GetCtsMode (Mac48Address address, WifiMode rtsMode) |
WifiMode | GetDataMode (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet, uint32_t fullPacketSize) |
WifiMode | GetDefaultMode (void) const |
uint32_t | GetFragmentationThreshold (void) const |
uint32_t | GetFragmentOffset (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet, uint32_t fragmentNumber) |
uint32_t | GetFragmentSize (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet, uint32_t fragmentNumber) |
WifiRemoteStationInfo | GetInfo (Mac48Address address) |
uint32_t | GetMaxSlrc (void) const |
uint32_t | GetMaxSsrc (void) const |
uint32_t | GetNBasicModes (void) const |
WifiMode | GetNonUnicastMode (void) const |
uint32_t | GetRtsCtsThreshold (void) const |
WifiMode | GetRtsMode (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet) |
bool | IsAssociated (Mac48Address address) const |
bool | IsBrandNew (Mac48Address address) const |
bool | IsLastFragment (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet, uint32_t fragmentNumber) |
bool | IsWaitAssocTxOk (Mac48Address address) const |
bool | NeedDataRetransmission (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet) |
bool | NeedFragmentation (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet) |
bool | NeedRts (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet) |
bool | NeedRtsRetransmission (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet) |
void | PrepareForQueue (Mac48Address address, const WifiMacHeader *header, Ptr< const Packet > packet, uint32_t fullPacketSize) |
void | RecordDisassociated (Mac48Address address) |
void | RecordGotAssocTxFailed (Mac48Address address) |
void | RecordGotAssocTxOk (Mac48Address address) |
void | RecordWaitAssocTxOk (Mac48Address address) |
void | ReportDataFailed (Mac48Address address, const WifiMacHeader *header) |
void | ReportDataOk (Mac48Address address, const WifiMacHeader *header, double ackSnr, WifiMode ackMode, double dataSnr) |
void | ReportFinalDataFailed (Mac48Address address, const WifiMacHeader *header) |
void | ReportFinalRtsFailed (Mac48Address address, const WifiMacHeader *header) |
void | ReportRtsFailed (Mac48Address address, const WifiMacHeader *header) |
void | ReportRtsOk (Mac48Address address, const WifiMacHeader *header, double ctsSnr, WifiMode ctsMode, double rtsSnr) |
void | ReportRxOk (Mac48Address address, const WifiMacHeader *header, double rxSnr, WifiMode txMode) |
void | Reset (void) |
void | Reset (Mac48Address address) |
void | SetFragmentationThreshold (uint32_t threshold) |
void | SetMaxSlrc (uint32_t maxSlrc) |
void | SetMaxSsrc (uint32_t maxSsrc) |
void | SetRtsCtsThreshold (uint32_t threshold) |
virtual void | SetupPhy (Ptr< WifiPhy > phy) |
| Object () |
virtual | ~Object () |
void | AggregateObject (Ptr< Object > other) |
void | Dispose (void) |
AggregateIterator | GetAggregateIterator (void) const |
virtual TypeId | GetInstanceTypeId (void) const |
template<typename T > |
Ptr< T > | GetObject (void) const |
template<typename T > |
Ptr< T > | GetObject (TypeId tid) const |
void | Start (void) |
| SimpleRefCount () |
| SimpleRefCount (const SimpleRefCount &o) |
uint32_t | GetReferenceCount (void) const |
SimpleRefCount & | operator= (const SimpleRefCount &o) |
void | Ref (void) const |
void | Unref (void) const |
virtual | ~ObjectBase () |
void | GetAttribute (std::string name, AttributeValue &value) const |
bool | GetAttributeFailSafe (std::string name, AttributeValue &attribute) const |
void | SetAttribute (std::string name, const AttributeValue &value) |
bool | SetAttributeFailSafe (std::string name, const AttributeValue &value) |
bool | TraceConnect (std::string name, std::string context, const CallbackBase &cb) |
bool | TraceConnectWithoutContext (std::string name, const CallbackBase &cb) |
bool | TraceDisconnect (std::string name, std::string context, const CallbackBase &cb) |
bool | TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb) |
ARF Rate control algorithm.
This class implements the so-called ARF algorithm which was initially described in WaveLAN-II: A High-performance wireless LAN for the unlicensed band, by A. Kamerman and L. Monteban. in Bell Lab Technical Journal, pages 118-133, Summer 1997.
This implementation differs from the initial description in that it uses a packet-based timer rather than a time-based timer as described in XXX (I cannot find back the original paper which described how the time-based timer could be easily replaced with a packet-based timer.)
ns3::ArfWifiManager is accessible through the following paths with Config::Set and Config::Connect:
-
/NodeList/[i]/DeviceList/[i]/$ns3::WifiNetDevice/RemoteStationManager/$ns3::ArfWifiManager
Attributes
-
TimerThreshold: The 'timer' threshold in the ARF algorithm.
-
SuccessThreshold: The minimum number of sucessfull transmissions to try a new rate.
-
IsLowLatency: If true, we attempt to modelize a so-called low-latency device: a device where decisions about tx parameters can be made on a per-packet basis and feedback about the transmission of each packet is obtained before sending the next. Otherwise, we modelize a high-latency device, that is a device where we cannot update our decision about tx parameters after every packet transmission.
-
MaxSsrc: The maximum number of retransmission attempts for an RTS. This value will not have any effect on some rate control algorithms.
-
MaxSlrc: The maximum number of retransmission attempts for a DATA packet. This value will not have any effect on some rate control algorithms.
-
RtsCtsThreshold: If the size of the data packet + LLC header + MAC header + FCS trailer is bigger than this value, we use an RTS/CTS handshake before sending the data, as per IEEE Std. 802.11-2007, Section 9.2.6. This value will not have any effect on some rate control algorithms.
-
FragmentationThreshold: If the size of the data packet + LLC header + MAC header + FCS trailer is biggerthan this value, we fragment it such that the size of the fragments are equal or smaller than this value, as per IEEE Std. 802.11-2007, Section 9.4. This value will not have any effect on some rate control algorithms.
-
NonUnicastMode: Wifi mode used for non-unicast transmissions.
-
Set with class: WifiModeValue
-
Underlying type: WifiMode
-
Initial value: Invalid-WifiMode
-
Flags: construct write read
No TraceSources are defined for this type.
-
MacTxRtsFailed: The transmission of a RTS by the MAC layer has failed
-
MacTxDataFailed: The transmission of a data packet by the MAC layer has failed
-
MacTxFinalRtsFailed: The transmission of a RTS has exceeded the maximum number of attempts
-
MacTxFinalDataFailed: The transmission of a data packet has exceeded the maximum number of attempts
Definition at line 42 of file arf-wifi-manager.h.
It is important to realize that "recovery" mode starts after failure of the first transmission after a rate increase and ends at the first successful transmission. Specifically, recovery mode transcends retransmissions boundaries. Fundamentally, ARF handles each data transmission independently, whether it is the initial transmission of a packet or the retransmission of a packet. The fundamental reason for this is that there is a backoff between each data transmission, be it an initial transmission or a retransmission.
Definition at line 103 of file arf-wifi-manager.cc.
References ns3::ArfWifiRemoteStation::m_failed, ns3::ArfWifiRemoteStation::m_rate, ns3::ArfWifiRemoteStation::m_recovery, ns3::ArfWifiRemoteStation::m_retry, ns3::ArfWifiRemoteStation::m_success, ns3::ArfWifiRemoteStation::m_timer, and NS_ASSERT.
