ns3::ErrorRateModel Class Reference
Wifi Models

the interface for Wifi's error models More...

#include <error-rate-model.h>

+ Inheritance diagram for ns3::ErrorRateModel:
+ Collaboration diagram for ns3::ErrorRateModel:

Public Member Functions

double CalculateSnr (WifiMode txMode, double ber) const
virtual double GetChunkSuccessRate (WifiMode mode, double snr, uint32_t nbits) const =0
- Public Member Functions inherited from ns3::Object
 Object ()
virtual ~Object ()
void AggregateObject (Ptr< Object > other)
void Dispose (void)
AggregateIterator GetAggregateIterator (void) const
virtual TypeId GetInstanceTypeId (void) const
template<typename T >
Ptr< T > GetObject (void) const
template<typename T >
Ptr< T > GetObject (TypeId tid) const
void Start (void)
- Public Member Functions inherited from ns3::SimpleRefCount< Object, ObjectBase, ObjectDeleter >
 SimpleRefCount ()
 SimpleRefCount (const SimpleRefCount &o)
uint32_t GetReferenceCount (void) const
SimpleRefCount & operator= (const SimpleRefCount &o)
void Ref (void) const
void Unref (void) const
- Public Member Functions inherited from ns3::ObjectBase
virtual ~ObjectBase ()
void GetAttribute (std::string name, AttributeValue &value) const
bool GetAttributeFailSafe (std::string name, AttributeValue &attribute) const
void SetAttribute (std::string name, const AttributeValue &value)
bool SetAttributeFailSafe (std::string name, const AttributeValue &value)
bool TraceConnect (std::string name, std::string context, const CallbackBase &cb)
bool TraceConnectWithoutContext (std::string name, const CallbackBase &cb)
bool TraceDisconnect (std::string name, std::string context, const CallbackBase &cb)
bool TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb)

Static Public Member Functions

static TypeId GetTypeId (void)
 This method returns the TypeId associated to ns3::ErrorRateModel.

Additional Inherited Members

- Protected Member Functions inherited from ns3::Object
 Object (const Object &o)
virtual void DoDispose (void)
virtual void DoStart (void)
virtual void NotifyNewAggregate (void)

Detailed Description

the interface for Wifi's error models

Definition at line 33 of file error-rate-model.h.

Member Function Documentation

double ns3::ErrorRateModel::CalculateSnr ( WifiMode  txMode,
double  ber
) const
Parameters
txModea specific transmission mode
bera target ber
Returns
the snr which corresponds to the requested ber.

Definition at line 35 of file error-rate-model.cc.

References GetChunkSuccessRate(), and NS_ASSERT.

Referenced by ns3::YansWifiPhy::CalculateSnr().

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

virtual double ns3::ErrorRateModel::GetChunkSuccessRate ( WifiMode  mode,
double  snr,
uint32_t  nbits
) const
pure virtual

Implemented in ns3::YansErrorRateModel, and ns3::NistErrorRateModel.

Referenced by ns3::InterferenceHelper::CalculateChunkSuccessRate(), and CalculateSnr().

+ Here is the caller graph for this function:

TypeId ns3::ErrorRateModel::GetTypeId ( void  )
static

This method returns the TypeId associated to ns3::ErrorRateModel.

No Attributes defined for this type.
No TraceSources defined for this type.

Reimplemented from ns3::Object.

Reimplemented in ns3::YansErrorRateModel, and ns3::NistErrorRateModel.

Definition at line 26 of file error-rate-model.cc.

References ns3::TypeId::SetParent().

+ Here is the call graph for this function:

The documentation for this class was generated from the following files:
