ns3::LteUeCmacSapUser Class Reference

#include <lte-ue-cmac-sap.h>

Inheritance diagram for ns3::LteUeCmacSapUser:

Public Member Functions
virtual	~LteUeCmacSapUser ()
virtual void	NotifyRandomAccessFailed ()=0
virtual void	NotifyRandomAccessSuccessful ()=0
virtual void	SetTemporaryCellRnti (uint16_t rnti)=0

Detailed Description

Service Access Point (SAP) offered by the UE MAC to the UE RRC

This is the MAC SAP User, i.e., the part of the SAP that contains the RRC methods called by the MAC

Definition at line 111 of file lte-ue-cmac-sap.h.

Constructor & Destructor Documentation

ns3::LteUeCmacSapUser::~LteUeCmacSapUser ( )

virtual

Definition at line 32 of file lte-ue-cmac-sap.cc.

Member Function Documentation

virtual void ns3::LteUeCmacSapUser::NotifyRandomAccessFailed ( )

pure virtual

Notify the RRC that the MAC Random Access procedure failed

Implemented in ns3::UeMemberLteUeCmacSapUser.

Referenced by ns3::LteUeMac::RaResponseTimeout().

Here is the caller graph for this function:

virtual void ns3::LteUeCmacSapUser::NotifyRandomAccessSuccessful ( )

pure virtual

Notify the RRC that the MAC Random Access procedure completed successfully

Implemented in ns3::UeMemberLteUeCmacSapUser.

Referenced by ns3::LteUeMac::RecvRaResponse().

Here is the caller graph for this function:

virtual void ns3::LteUeCmacSapUser::SetTemporaryCellRnti ( uint16_t  rnti )

pure virtual

Parameters

rnti	the T-C-RNTI, which will eventually become the C-RNTI after contention resolution

Implemented in ns3::UeMemberLteUeCmacSapUser.

Referenced by ns3::LteUeMac::RecvRaResponse().

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/lte/model/lte-ue-cmac-sap.h
• src/lte/model/lte-ue-cmac-sap.cc
