ns3::PacketTagIterator::Item Class Reference

Identifies a packet tag within a packet. More...

#include <packet.h>

+ Collaboration diagram for ns3::PacketTagIterator::Item:

Public Member Functions

void GetTag (Tag &tag) const
 Read the requested tag and store it in the user-provided tag instance. More...

TypeId GetTypeId (void) const


Private Member Functions

 Item (const struct PacketTagList::TagData *data)


Private Attributes

const struct
PacketTagList::TagData
m_data


Friends

class PacketTagIterator


Detailed Description

Identifies a packet tag within a packet.

Definition at line 119 of file packet.h.

Constructor & Destructor Documentation

ns3::PacketTagIterator::Item::Item ( const struct PacketTagList::TagData data)
private

Definition at line 102 of file packet.cc.

Member Function Documentation

void ns3::PacketTagIterator::Item::GetTag ( Tag tag) const

Read the requested tag and store it in the user-provided tag instance.

Parameters
tagthe user tag to which the data should be copied.

This method will crash if the type of the tag provided by the user does not match the type of the underlying tag.

Definition at line 112 of file packet.cc.

References ns3::Tag::Deserialize(), ns3::ObjectBase::GetInstanceTypeId(), ns3::PacketTagList::TagData::MAX_SIZE, and NS_ASSERT.

Referenced by ns3::Packet::PrintPacketTags().

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

TypeId ns3::PacketTagIterator::Item::GetTypeId ( void  ) const
Returns
the ns3::TypeId associated to this tag.

Definition at line 107 of file packet.cc.

Referenced by ns3::Packet::PrintPacketTags().

+ Here is the caller graph for this function:

Friends And Related Function Documentation

friend class PacketTagIterator
friend

Definition at line 136 of file packet.h.

Member Data Documentation

const struct PacketTagList::TagData* ns3::PacketTagIterator::Item::m_data
private

Definition at line 138 of file packet.h.


The documentation for this class was generated from the following files:
