anonymous_namespace{rng-stream.cc} Namespace Reference

Classes
struct	Precalculated

Typedefs
typedef double	Matrix [3][3]

Functions
void	MatMatModM (const Matrix A, const Matrix B, Matrix C, double m)
void	MatTwoPowModM (const Matrix src, Matrix dst, double m, int32_t e)
void	MatVecModM (const Matrix A, const double s[3], double v[3], double m)
double	MultModM (double a, double s, double c, double m)
struct Precalculated	PowerOfTwoConstants (void)
void	PowerOfTwoMatrix (int n, Matrix a1p, Matrix a2p)

Variables
const double	a12 = 1403580.0
const double	a13n = 810728.0
const Matrix	A1p0
const double	a21 = 527612.0
const double	a23n = 1370589.0
const Matrix	A2p0
const double	m1 = 4294967087.0
const double	m2 = 4294944443.0
const double	norm = 1.0 / (m1 + 1.0)
const double	two17 = 131072.0
const double	two53 = 9007199254740992.0

Typedef Documentation

typedef double anonymous_namespace{rng-stream.cc}::Matrix[3][3]

Definition at line 37 of file rng-stream.cc.

Function Documentation

void anonymous_namespace{rng-stream.cc}::MatMatModM	(	const Matrix	A,
		const Matrix	B,
		Matrix	C,
		double	m
	)

Definition at line 122 of file rng-stream.cc.

References MatVecModM().

Referenced by MatTwoPowModM().

Here is the call graph for this function:

Here is the caller graph for this function:

void anonymous_namespace{rng-stream.cc}::MatTwoPowModM	(	const Matrix	src,
		Matrix	dst,
		double	m,
		int32_t	e
	)

Definition at line 154 of file rng-stream.cc.

References MatMatModM().

Referenced by PowerOfTwoConstants().

Here is the call graph for this function:

Here is the caller graph for this function:

void anonymous_namespace{rng-stream.cc}::MatVecModM	(	const Matrix	A,
		const double	s[3],
		double	v[3],
		double	m
	)

Definition at line 99 of file rng-stream.cc.

References MultModM(), and sample-rng-plot::x.

Referenced by ns3::RngStream::AdvanceNthBy(), and MatMatModM().

Here is the call graph for this function:

Here is the caller graph for this function:

double anonymous_namespace{rng-stream.cc}::MultModM	(	double	a,
		double	s,
		double	c,
		double	m
	)

Definition at line 65 of file rng-stream.cc.

References s, and two17.

Referenced by MatVecModM().

Here is the caller graph for this function:

struct Precalculated anonymous_namespace{rng-stream.cc}::PowerOfTwoConstants

(

void

)

Definition at line 218 of file rng-stream.cc.

References anonymous_namespace{rng-stream.cc}::Precalculated::a1, anonymous_namespace{rng-stream.cc}::Precalculated::a2, and MatTwoPowModM().

Referenced by PowerOfTwoMatrix().

Here is the call graph for this function:

Here is the caller graph for this function:

void anonymous_namespace{rng-stream.cc}::PowerOfTwoMatrix	(	int	n,
		Matrix	a1p,
		Matrix	a2p
	)

Definition at line 229 of file rng-stream.cc.

References anonymous_namespace{rng-stream.cc}::Precalculated::a1, anonymous_namespace{rng-stream.cc}::Precalculated::a2, and PowerOfTwoConstants().

Referenced by ns3::RngStream::AdvanceNthBy().

Here is the call graph for this function:

Here is the caller graph for this function:

Variable Documentation

const double anonymous_namespace{rng-stream.cc}::a12 = 1403580.0

Definition at line 42 of file rng-stream.cc.

Referenced by ns3::RngStream::RandU01().

const double anonymous_namespace{rng-stream.cc}::a13n = 810728.0

Definition at line 43 of file rng-stream.cc.

Referenced by ns3::RngStream::RandU01().

const Matrix anonymous_namespace{rng-stream.cc}::A1p0

Initial value:

= {
  {       0.0,        1.0,       0.0 },
  {       0.0,        0.0,       1.0 },
  { -810728.0,  1403580.0,       0.0 }
}

Definition at line 49 of file rng-stream.cc.

const double anonymous_namespace{rng-stream.cc}::a21 = 527612.0

Definition at line 44 of file rng-stream.cc.

Referenced by ns3::RngStream::RandU01().

const double anonymous_namespace{rng-stream.cc}::a23n = 1370589.0

Definition at line 45 of file rng-stream.cc.

Referenced by ns3::RngStream::RandU01().

const Matrix anonymous_namespace{rng-stream.cc}::A2p0

Initial value:

= {
  {        0.0,        1.0,       0.0 },
  {        0.0,        0.0,       1.0 },
  { -1370589.0,        0.0,  527612.0 }
}

Definition at line 55 of file rng-stream.cc.

const double anonymous_namespace{rng-stream.cc}::m1 = 4294967087.0

Definition at line 39 of file rng-stream.cc.

Referenced by ns3::RngStream::AdvanceNthBy(), UanTest::DoPhyTests(), PbbTestSuite::PbbTestSuite(), ns3::RngStream::RandU01(), and ns3::RngStream::RngStream().

const double anonymous_namespace{rng-stream.cc}::m2 = 4294944443.0

Definition at line 40 of file rng-stream.cc.

Referenced by ns3::RngStream::AdvanceNthBy(), PbbTestSuite::PbbTestSuite(), ns3::RngStream::RandU01(), and ns3::RngStream::RngStream().

const double anonymous_namespace{rng-stream.cc}::norm = 1.0 / (m1 + 1.0)

Definition at line 41 of file rng-stream.cc.

Referenced by ns3::RngStream::RandU01().

const double anonymous_namespace{rng-stream.cc}::two17 = 131072.0

Definition at line 46 of file rng-stream.cc.

Referenced by MultModM().

const double anonymous_namespace{rng-stream.cc}::two53 = 9007199254740992.0

Definition at line 47 of file rng-stream.cc.
