Public Member Functions | |
TxDurationTest () | |
virtual | ~TxDurationTest () |
virtual void | DoRun (void) |
Implementation to actually run this TestCase. More... | |
![]() | |
virtual | ~TestCase () |
Destructor. More... | |
std::string | GetName (void) const |
Private Member Functions | |
bool | CheckPayloadDuration (uint32_t size, WifiMode payloadMode, uint32_t channelWidth, bool isShortGuardInterval, WifiPreamble preamble, uint32_t knownDurationMicroSeconds) |
Check if the payload tx duration returned by InterferenceHelper corresponds to a known value of the pay. More... | |
bool | CheckTxDuration (uint32_t size, WifiMode payloadMode, uint32_t channelWidth, bool isShortGuardInterval, WifiPreamble preamble, double knownDurationMicroSeconds) |
Check if the overall tx duration returned by InterferenceHelper corresponds to a known value of the pay. More... | |
Additional Inherited Members | |
![]() | |
enum | TestDuration { QUICK = 1, EXTENSIVE = 2, TAKES_FOREVER = 3 } |
How long the test takes to execute. More... | |
![]() | |
TestCase (std::string name) | |
Constructor. More... | |
void | AddTestCase (TestCase *testCase, enum TestDuration duration) |
Add an individual child TestCase to this test suite. More... | |
TestCase * | GetParent () const |
Get the parent of this TestCsse. More... | |
bool | IsStatusFailure (void) const |
Check if any tests failed. More... | |
bool | IsStatusSuccess (void) const |
Check if all tests passed. More... | |
void | SetDataDir (std::string directory) |
Set the data directory where reference trace files can be found. More... | |
void | ReportTestFailure (std::string cond, std::string actual, std::string limit, std::string message, std::string file, int32_t line) |
Log the failure of this TestCase. More... | |
bool | MustAssertOnFailure (void) const |
Check if this run should assert on failure. More... | |
bool | MustContinueOnFailure (void) const |
Check if this run should continue on failure. More... | |
std::string | CreateDataDirFilename (std::string filename) |
Construct the full path to a file in the data directory. More... | |
std::string | CreateTempDirFilename (std::string filename) |
Construct the full path to a file in a temporary directory. More... | |
Definition at line 36 of file tx-duration-test.cc.
TxDurationTest::TxDurationTest | ( | ) |
Definition at line 76 of file tx-duration-test.cc.
|
virtual |
Definition at line 81 of file tx-duration-test.cc.
|
private |
Check if the payload tx duration returned by InterferenceHelper corresponds to a known value of the pay.
size | size of payload in octets (includes everything after the PLCP header) |
payloadMode | the WifiMode used |
channelWidth | the channel width used (in MHz) |
isShortGuardInterval | whether short guard interval is used |
knownDurationMicroSeconds | the known duration value of the transmission in microseconds |
Definition at line 86 of file tx-duration-test.cc.
References CHANNEL_1_MHZ, CHANNEL_36_MHZ, ns3::WifiMode::GetDataRate(), ns3::Time::GetMicroSeconds(), ns3::WifiMode::GetModulationClass(), ns3::WifiPhy::GetPayloadDuration(), third::phy, ns3::WifiTxVector::SetChannelWidth(), ns3::WifiTxVector::SetMode(), ns3::WifiTxVector::SetNess(), ns3::WifiTxVector::SetNss(), ns3::WifiTxVector::SetShortGuardInterval(), ns3::WifiTxVector::SetStbc(), ns3::WIFI_MOD_CLASS_HT, ns3::WIFI_MOD_CLASS_OFDM, and ns3::WIFI_MOD_CLASS_VHT.
Referenced by DoRun().
|
private |
Check if the overall tx duration returned by InterferenceHelper corresponds to a known value of the pay.
size | size of payload in octets (includes everything after the PLCP header) |
payloadMode | the WifiMode used |
channelWidth | the channel width used (in MHz) |
isShortGuardInterval | whether short guard interval is used |
preamble | the WifiPreamble used |
knownDurationMicroSeconds | the known duration value of the transmission in microseconds |
Definition at line 134 of file tx-duration-test.cc.
References ns3::WifiPhy::CalculateTxDuration(), CHANNEL_1_MHZ, CHANNEL_36_MHZ, ns3::WifiMode::GetDataRate(), ns3::WifiMode::GetModulationClass(), ns3::Time::GetNanoSeconds(), third::phy, ns3::WifiTxVector::SetChannelWidth(), ns3::WifiTxVector::SetMode(), ns3::WifiTxVector::SetNess(), ns3::WifiTxVector::SetNss(), ns3::WifiTxVector::SetShortGuardInterval(), ns3::WifiTxVector::SetStbc(), ns3::WIFI_MOD_CLASS_HT, ns3::WIFI_MOD_CLASS_OFDM, and ns3::WIFI_MOD_CLASS_VHT.
Referenced by DoRun().
|
virtual |
Implementation to actually run this TestCase.
Subclasses should override this method to conduct their tests.
Implements ns3::TestCase.
Definition at line 184 of file tx-duration-test.cc.
References CheckPayloadDuration(), CheckTxDuration(), NS_TEST_EXPECT_MSG_EQ, ns3::WIFI_PREAMBLE_HT_GF, ns3::WIFI_PREAMBLE_HT_MF, ns3::WIFI_PREAMBLE_LONG, ns3::WIFI_PREAMBLE_SHORT, and ns3::WIFI_PREAMBLE_VHT.
