This class is an adaptor between class SpectrumWifiPhy (which inherits from WifiPhy) and class SpectrumChannel (which expects objects derived from class SpectrumPhy to be connected to it). More...

#include "wifi-spectrum-phy-interface.h"

Inheritance diagram for ns3::WifiSpectrumPhyInterface:

Collaboration diagram for ns3::WifiSpectrumPhyInterface:

Public Member Functions
	WifiSpectrumPhyInterface ()

virtual Ptr< NetDevice >	GetDevice () const
	Get the associated NetDevice instance. More...

virtual Ptr< MobilityModel >	GetMobility ()
	Get the associated MobilityModel instance. More...

virtual Ptr< AntennaModel >	GetRxAntenna ()
	Get the AntennaModel used by the NetDevice for reception. More...

virtual Ptr< const SpectrumModel >	GetRxSpectrumModel () const

virtual void	SetChannel (Ptr< SpectrumChannel > c)
	Set the channel attached to this device. More...

virtual void	SetDevice (Ptr< NetDevice > d)
	Set the associated NetDevice instance. More...

virtual void	SetMobility (Ptr< MobilityModel > m)
	Set the mobility model associated with this device. More...

void	SetSpectrumWifiPhy (Ptr< SpectrumWifiPhy > phy)
	Connect SpectrumWifiPhy object. More...

virtual void	StartRx (Ptr< SpectrumSignalParameters > params)
	Notify the SpectrumPhy instance of an incoming signal. More...

Public Member Functions inherited from ns3::SpectrumPhy
	SpectrumPhy ()

virtual	~SpectrumPhy ()

Public Member Functions inherited from ns3::Object
	Object ()
	Constructor. More...

virtual	~Object ()
	Destructor. More...

void	AggregateObject (Ptr< Object > other)
	Aggregate two Objects together. More...

void	Dispose (void)
	Dispose of this Object. More...

AggregateIterator	GetAggregateIterator (void) const
	Get an iterator to the Objects aggregated to this one. More...

virtual TypeId	GetInstanceTypeId (void) const
	Implement the GetInstanceTypeId method defined in ObjectBase. More...

template<typename T >
Ptr< T >	GetObject (void) const
	Get a pointer to the requested aggregated Object. More...

template<typename T >
Ptr< T >	GetObject (TypeId tid) const
	Get a pointer to the requested aggregated Object by TypeId. More...

void	Initialize (void)
	Invoke DoInitialize on all Objects aggregated to this one. More...

bool	IsInitialized (void) const
	Check if the object has been initialized. More...

Public Member Functions inherited from ns3::SimpleRefCount< Object, ObjectBase, ObjectDeleter >
	SimpleRefCount ()
	Constructor. More...

	SimpleRefCount (const SimpleRefCount &o)
	Copy constructor. More...

uint32_t	GetReferenceCount (void) const
	Get the reference count of the object. More...

SimpleRefCount &	operator= (const SimpleRefCount &o)
	Assignment. More...

void	Ref (void) const
	Increment the reference count. More...

void	Unref (void) const
	Decrement the reference count. More...

Public Member Functions inherited from ns3::ObjectBase
virtual	~ObjectBase ()
	Virtual destructor. More...

void	GetAttribute (std::string name, AttributeValue &value) const
	Get the value of an attribute, raising fatal errors if unsuccessful. More...

bool	GetAttributeFailSafe (std::string name, AttributeValue &value) const
	Get the value of an attribute without raising erros. More...

void	SetAttribute (std::string name, const AttributeValue &value)
	Set a single attribute, raising fatal errors if unsuccessful. More...

bool	SetAttributeFailSafe (std::string name, const AttributeValue &value)
	Set a single attribute without raising errors. More...

bool	TraceConnect (std::string name, std::string context, const CallbackBase &cb)
	Connect a TraceSource to a Callback with a context. More...

bool	TraceConnectWithoutContext (std::string name, const CallbackBase &cb)
	Connect a TraceSource to a Callback without a context. More...

bool	TraceDisconnect (std::string name, std::string context, const CallbackBase &cb)
	Disconnect from a TraceSource a Callback previously connected with a context. More...

bool	TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb)
	Disconnect from a TraceSource a Callback previously connected without a context. More...

Static Public Member Functions
static TypeId	GetTypeId (void)

Static Public Member Functions inherited from ns3::SpectrumPhy
static TypeId	GetTypeId (void)
	Get the type ID. More...

Static Public Member Functions inherited from ns3::Object
static TypeId	GetTypeId (void)
	Register this type. More...

Static Public Member Functions inherited from ns3::SimpleRefCount< Object, ObjectBase, ObjectDeleter >
static void	Cleanup (void)
	Noop. More...

Static Public Member Functions inherited from ns3::ObjectBase
static TypeId	GetTypeId (void)
	Get the type ID. More...

Private Member Functions
virtual void	DoDispose (void)
	Destructor implementation. More...

Private Attributes
Ptr< SpectrumChannel >	m_channel

Ptr< NetDevice >	m_netDevice

Ptr< SpectrumWifiPhy >	m_spectrumWifiPhy

Additional Inherited Members
Protected Member Functions inherited from ns3::Object
	Object (const Object &o)
	Copy an Object. More...

virtual void	DoInitialize (void)
	Initialize() implementation. More...

virtual void	NotifyNewAggregate (void)
	Notify all Objects aggregated to this one of a new Object being aggregated. More...

Protected Member Functions inherited from ns3::ObjectBase
void	ConstructSelf (const AttributeConstructionList &attributes)
	Complete construction of ObjectBase; invoked by derived classes. More...

virtual void	NotifyConstructionCompleted (void)
	Notifier called once the ObjectBase is fully constructed. More...

Related Functions inherited from ns3::ObjectBase
static TypeId	GetObjectIid (void)
	Ensure the TypeId for ObjectBase gets fully configured to anchor the inheritance tree properly. More...

Detailed Description

This class is an adaptor between class SpectrumWifiPhy (which inherits from WifiPhy) and class SpectrumChannel (which expects objects derived from class SpectrumPhy to be connected to it).

Introspection did not find any typical Config paths.

The adaptor is used only in the receive direction; in the transmit direction, the class SpectrumWifiPhy constructs signal parameters and directly accesses the SpectrumChannel

No Attributes are defined for this type.
No TraceSources are defined for this type.
Size of this type is 56 bytes (on a 64-bit architecture).

Definition at line 42 of file wifi-spectrum-phy-interface.h.

Constructor & Destructor Documentation

ns3::WifiSpectrumPhyInterface::WifiSpectrumPhyInterface ( )

Definition at line 50 of file wifi-spectrum-phy-interface.cc.

References NS_LOG_FUNCTION.

Member Function Documentation

void ns3::WifiSpectrumPhyInterface::DoDispose ( void )

privatevirtual

Destructor implementation.

This method is called by Dispose() or by the Object's destructor, whichever comes first.

Subclasses are expected to implement their real destruction code in an overriden version of this method and chain up to their parent's implementation once they are done. i.e, for simplicity, the destructor of every subclass should be empty and its content should be moved to the associated DoDispose() method.

It is safe to call GetObject() from within this method.

Reimplemented from ns3::Object.

Definition at line 56 of file wifi-spectrum-phy-interface.cc.

References m_channel, m_netDevice, m_spectrumWifiPhy, and NS_LOG_FUNCTION.

Ptr< NetDevice > ns3::WifiSpectrumPhyInterface::GetDevice ( ) const

virtual

Get the associated NetDevice instance.

Returns: a Ptr to the associated NetDevice instance

Implements ns3::SpectrumPhy.

Definition at line 70 of file wifi-spectrum-phy-interface.cc.

References m_netDevice.

Ptr< MobilityModel > ns3::WifiSpectrumPhyInterface::GetMobility ( )

virtual

Get the associated MobilityModel instance.

Returns: a Ptr to the associated MobilityModel instance

Implements ns3::SpectrumPhy.

Definition at line 76 of file wifi-spectrum-phy-interface.cc.

References ns3::WifiPhy::GetMobility(), and m_spectrumWifiPhy.

Here is the call graph for this function:

Ptr< AntennaModel > ns3::WifiSpectrumPhyInterface::GetRxAntenna ( )

virtual

Get the AntennaModel used by the NetDevice for reception.

Returns: a Ptr to the AntennaModel used by the NetDevice for reception

Implements ns3::SpectrumPhy.

Definition at line 107 of file wifi-spectrum-phy-interface.cc.

References ns3::SpectrumWifiPhy::GetRxAntenna(), m_spectrumWifiPhy, and NS_LOG_FUNCTION.

Here is the call graph for this function:

Ptr< const SpectrumModel > ns3::WifiSpectrumPhyInterface::GetRxSpectrumModel ( ) const

virtual

Returns: returns the SpectrumModel that this SpectrumPhy expects to be used for all SpectrumValues that are passed to StartRx. If 0 is returned, it means that any model will be accepted.

Implements ns3::SpectrumPhy.

Definition at line 101 of file wifi-spectrum-phy-interface.cc.

References ns3::SpectrumWifiPhy::GetRxSpectrumModel(), and m_spectrumWifiPhy.

Here is the call graph for this function:
