802.11 PHY layer model More...

#include <wifi-phy.h>

Inheritance diagram for ns3::WifiPhy:

Collaboration diagram for ns3::WifiPhy:

Public Types
enum	State { SYNC, TX, CCA_BUSY, IDLE }
typedef Callback< void, Ptr < Packet >, double, WifiMode, enum WifiPreamble >	SyncOkCallback
typedef Callback< void, Ptr < const Packet >, double >	SyncErrorCallback
Public Member Functions
virtual uint32_t	GetNTxPower (void) const =0
virtual void	SetReceiveOkCallback (SyncOkCallback callback)=0
virtual void	SetReceiveErrorCallback (SyncErrorCallback callback)=0
virtual void	SendPacket (Ptr< const Packet > packet, WifiMode mode, enum WifiPreamble preamble, uint8_t txPowerLevel)=0
virtual void	RegisterListener (WifiPhyListener *listener)=0
virtual bool	IsStateCcaBusy (void)=0
virtual bool	IsStateIdle (void)=0
virtual bool	IsStateBusy (void)=0
virtual bool	IsStateSync (void)=0
virtual bool	IsStateTx (void)=0
virtual Time	GetStateDuration (void)=0
virtual Time	GetDelayUntilIdle (void)=0
virtual Time	CalculateTxDuration (uint32_t size, WifiMode payloadMode, enum WifiPreamble preamble) const =0
virtual uint32_t	GetNModes (void) const =0
virtual WifiMode	GetMode (uint32_t mode) const =0
virtual double	CalculateSnr (WifiMode txMode, double ber) const =0
Static Public Member Functions
static TypeId	GetTypeId (void)
	This method returns the TypeId associated to ns3::WifiPhy.

Detailed Description

802.11 PHY layer model

Member Typedef Documentation

typedef Callback<void,Ptr<const Packet>, double> ns3::WifiPhy::SyncErrorCallback

arg1: packet received unsuccessfully arg2: snr of packet

typedef Callback<void,Ptr<Packet>, double, WifiMode, enum WifiPreamble> ns3::WifiPhy::SyncOkCallback

arg1: packet received successfully arg2: snr of packet arg3: mode of packet arg4: type of preamble used for packet.

Member Enumeration Documentation

enum ns3::WifiPhy::State

The state of the PHY layer.

Enumerator:

SYNC	The PHY layer is synchronized upon a packet.
TX	The PHY layer is sending a packet.
CCA_BUSY	The PHY layer has sense the medium busy through the CCA mechanism
IDLE	The PHY layer is IDLE.

Member Function Documentation

virtual double ns3::WifiPhy::CalculateSnr	(	WifiMode	txMode,
		double	ber
	)			const `[pure virtual]`

Parameters:

	txMode	the transmission mode
	ber	the probability of bit error rate

Returns:: the minimum snr which is required to achieve the requested ber for the specified transmission mode. (W/W)

Implemented in ns3::YansWifiPhy.

virtual Time ns3::WifiPhy::CalculateTxDuration	(	uint32_t	size,
		WifiMode	payloadMode,
		enum WifiPreamble	preamble
	)			const `[pure virtual]`

Parameters:

	size	the number of bytes in the packet to send
	payloadMode	the transmission mode to use for this packet
	preamble	the type of preamble to use for this packet.

Returns:: the total amount of time this PHY will stay busy for the transmission of these bytes.

Implemented in ns3::YansWifiPhy.

virtual Time ns3::WifiPhy::GetDelayUntilIdle ( void ) [pure virtual]

Returns:: the predicted delay until this PHY can become WifiPhy::IDLE.

The PHY will never become WifiPhy::IDLE _before_ the delay returned by this method but it could become really idle later.

Implemented in ns3::YansWifiPhy.

virtual WifiMode ns3::WifiPhy::GetMode ( uint32_t mode ) const [pure virtual]

Parameters:

mode

index in array of supported modes

Returns:: the mode whose index is specified.

Implemented in ns3::YansWifiPhy.

virtual uint32_t ns3::WifiPhy::GetNModes ( void ) const [pure virtual]

Returns:: the number of transmission modes supported by this PHY.

Implemented in ns3::YansWifiPhy.

virtual uint32_t ns3::WifiPhy::GetNTxPower ( void ) const [pure virtual]

Returns:: the number of tx power levels available for this PHY.

Implemented in ns3::YansWifiPhy.

virtual Time ns3::WifiPhy::GetStateDuration ( void ) [pure virtual]

Returns:: the amount of time since the current state has started.

Implemented in ns3::YansWifiPhy.

static TypeId ns3::WifiPhy::GetTypeId ( void ) [static]

This method returns the TypeId associated to ns3::WifiPhy.

This object is accessible through the following paths with Config::Set and Config::Connect:

/NodeList/[i]/DeviceList/[i]/$ns3WifiNetDevice/Phy

No Attributes defined for this type.
No TraceSources defined for this type.

Reimplemented from ns3::Object.

Reimplemented in ns3::YansWifiPhy.

virtual bool ns3::WifiPhy::IsStateBusy ( void ) [pure virtual]

Returns:: true of the current state of the PHY layer is not WifiPhy::IDLE, false otherwise.

Implemented in ns3::YansWifiPhy.

virtual bool ns3::WifiPhy::IsStateCcaBusy ( void ) [pure virtual]

Returns:: true of the current state of the PHY layer is WifiPhy::CCA_BUSY, false otherwise.

Implemented in ns3::YansWifiPhy.

virtual bool ns3::WifiPhy::IsStateIdle ( void ) [pure virtual]

Returns:: true of the current state of the PHY layer is WifiPhy::IDLE, false otherwise.

Implemented in ns3::YansWifiPhy.

virtual bool ns3::WifiPhy::IsStateSync ( void ) [pure virtual]

Returns:: true of the current state of the PHY layer is WifiPhy::SYNC, false otherwise.

Implemented in ns3::YansWifiPhy.

virtual bool ns3::WifiPhy::IsStateTx ( void ) [pure virtual]

Returns:: true of the current state of the PHY layer is WifiPhy::TX, false otherwise.

Implemented in ns3::YansWifiPhy.

virtual void ns3::WifiPhy::RegisterListener ( WifiPhyListener * listener ) [pure virtual]

Parameters:

listener

the new listener

Add the input listener to the list of objects to be notified of PHY-level events.

Implemented in ns3::YansWifiPhy.

virtual void ns3::WifiPhy::SendPacket	(	Ptr< const Packet >	packet,
		WifiMode	mode,
		enum WifiPreamble	preamble,
		uint8_t	txPowerLevel
	)			`[pure virtual]`

Parameters:

	packet	the packet to send
	mode	the transmission mode to use to send this packet
	preamble	the type of preamble to use to send this packet.
	txPowerLevel	a power level to use to send this packet. The real transmission power is calculated as txPowerMin + txPowerLevel * (txPowerMax - txPowerMin) / nTxLevels
