an application which sends one ICMP ECHO request, waits for a REPLYs and reports the calculated RTT. More...
#include <v4ping.h>
Public Member Functions | |
| V4Ping () | |
Static Public Member Functions | |
| static TypeId | GetTypeId (void) |
| This method returns the TypeId associated to ns3::V4Ping. | |
Private Member Functions | |
| virtual void | StartApplication (void) |
| Application specific startup code. | |
| virtual void | StopApplication (void) |
| Application specific shutdown code. | |
| virtual void | DoDispose (void) |
Detailed Description
an application which sends one ICMP ECHO request, waits for a REPLYs and reports the calculated RTT.
Note: The RTT calculated is reported through a trace source.
Constructor & Destructor Documentation
| ns3::V4Ping::V4Ping | ( | ) |
create a pinger applications
Member Function Documentation
| virtual void ns3::V4Ping::DoDispose | ( | void | ) | [private, virtual] |
This method is called by Object::Dispose or by the object's destructor, whichever comes first.
Subclasses are expected to implement their real destruction code in an overriden version of this method and chain up to their parent's implementation once they are done. i.e., for simplicity, the destructor of every subclass should be empty and its content should be moved to the associated DoDispose method.
Reimplemented from ns3::Application.
| static TypeId ns3::V4Ping::GetTypeId | ( | void | ) | [static] |
This method returns the TypeId associated to ns3::V4Ping.
This object is accessible through the following paths with Config::Set and Config::Connect:
- /NodeList/[i]/ApplicationList/[i]/$ns3::V4Ping
Attributes defined for this type:
-
Remote: The address of the machine we want to ping.
- Set with class: Ipv4AddressValue
- Underlying type: Ipv4Address
- Initial value: 102.102.102.102
- Flags: construct write read
TraceSources defined for this type:
- Rtt: The rtt calculated by the ping.
Reimplemented from ns3::Application.
| virtual void ns3::V4Ping::StartApplication | ( | void | ) | [private, virtual] |
Application specific startup code.
The StartApplication method is called at the start time specifed by Start This method should be overridden by all or most application subclasses.
Reimplemented from ns3::Application.
| virtual void ns3::V4Ping::StopApplication | ( | void | ) | [private, virtual] |
Application specific shutdown code.
The StopApplication method is called at the stop time specifed by Stop This method should be overridden by all or most application subclasses.
Reimplemented from ns3::Application.
The documentation for this class was generated from the following files:
- src/applications/v4ping/v4ping.h
- doc/introspected-doxygen.h
