IPv6 Option base. More...
#include <ipv6-option.h>
Public Member Functions | |
| virtual | ~Ipv6Option () |
| Destructor. | |
| void | SetNode (Ptr< Node > node) |
| Set the node. | |
| virtual uint8_t | GetOptionNumber () const =0 |
| Get the option number. | |
| virtual uint8_t | Process (Ptr< Packet > packet, uint8_t offset, Ipv6Header const &ipv6Header, bool &isDropped)=0 |
| Process method. | |
Static Public Member Functions | |
| static TypeId | GetTypeId () |
| Get the type identificator. | |
Detailed Description
IPv6 Option base.
If you want to implement a new IPv6 option, all you have to do is implement a subclass of this class and add it to an Ipv6OptionDemux.
Member Function Documentation
| virtual uint8_t ns3::Ipv6Option::GetOptionNumber | ( | ) | const [pure virtual] |
Get the option number.
- Returns:
- option number
Implemented in ns3::Ipv6OptionPad1, ns3::Ipv6OptionPadn, ns3::Ipv6OptionJumbogram, and ns3::Ipv6OptionRouterAlert.
| static TypeId ns3::Ipv6Option::GetTypeId | ( | void | ) | [static] |
Get the type identificator.
This method returns the TypeId associated to ns3::Ipv6Option.
- Returns:
- type identificator
Attributes defined for this type:
-
OptionNumber: The IPv6 option number.
- Set with class: ns3::UintegerValue
- Underlying type: uint8_t 0:255
- Flags: read
No TraceSources defined for this type.
Reimplemented from ns3::Object.
Reimplemented in ns3::Ipv6OptionPad1, ns3::Ipv6OptionPadn, ns3::Ipv6OptionJumbogram, and ns3::Ipv6OptionRouterAlert.
| virtual uint8_t ns3::Ipv6Option::Process | ( | Ptr< Packet > | packet, | |
| uint8_t | offset, | |||
| Ipv6Header const & | ipv6Header, | |||
| bool & | isDropped | |||
| ) | [pure virtual] |
Process method.
Called from Ipv6L3Protocol::Receive.
- Parameters:
-
packet the packet offset the offset of the extension to process ipv6Header the IPv6 header of packet received isDropped if the packet must be dropped
- Returns:
- the processed size
Implemented in ns3::Ipv6OptionPad1, ns3::Ipv6OptionPadn, ns3::Ipv6OptionJumbogram, and ns3::Ipv6OptionRouterAlert.
The documentation for this class was generated from the following files:
- src/internet-stack/ipv6-option.h
- doc/introspected-doxygen.h
