ns3::DcaTxop::TransmissionListener Class Reference

Inheritance diagram for ns3::DcaTxop::TransmissionListener:

Collaboration diagram for ns3::DcaTxop::TransmissionListener:

Public Member Functions
	TransmissionListener (DcaTxop *txop)
virtual	~TransmissionListener ()
virtual void	Cancel (void)
virtual void	GotAck (double snr, WifiMode txMode)
virtual void	GotCts (double snr, WifiMode txMode)
virtual void	MissedAck (void)
virtual void	MissedCts (void)
virtual void	StartNext (void)
Public Member Functions inherited from ns3::MacLowTransmissionListener
	MacLowTransmissionListener ()
virtual	~MacLowTransmissionListener ()
virtual void	GotBlockAck (const CtrlBAckResponseHeader *blockAck, Mac48Address source)
virtual void	MissedBlockAck (void)

Private Attributes
DcaTxop *	m_txop

Detailed Description

Definition at line 72 of file dca-txop.cc.

Constructor & Destructor Documentation

ns3::DcaTxop::TransmissionListener::TransmissionListener ( DcaTxop *  txop )

inline

Definition at line 75 of file dca-txop.cc.

virtual ns3::DcaTxop::TransmissionListener::~TransmissionListener ( )

inlinevirtual

Definition at line 80 of file dca-txop.cc.

Member Function Documentation

virtual void ns3::DcaTxop::TransmissionListener::Cancel ( void  )

inlinevirtual

Invoked if this transmission was canceled one way or another. When this method is invoked, you can assume that the packet has not been passed down the stack to the PHY.

Implements ns3::MacLowTransmissionListener.

Definition at line 102 of file dca-txop.cc.

References ns3::DcaTxop::Cancel(), and m_txop.

Here is the call graph for this function:

virtual void ns3::DcaTxop::TransmissionListener::GotAck ( double  snr, WifiMode  txMode  )

inlinevirtual

Parameters

snr	the snr of the ack
txMode	the transmission mode of the ack

ns3::MacLow received an expected ACL within AckTimeout. The snr and txMode arguments are not valid when SUPER_FAST_ACK is used.

Implements ns3::MacLowTransmissionListener.

Definition at line 90 of file dca-txop.cc.

References ns3::DcaTxop::GotAck(), and m_txop.

Here is the call graph for this function:

virtual void ns3::DcaTxop::TransmissionListener::GotCts ( double  snr, WifiMode  txMode  )

inlinevirtual

Parameters

snr	the snr of the cts
txMode	the txMode of the cts

ns3::MacLow received an expected CTS within CtsTimeout.

Implements ns3::MacLowTransmissionListener.

Definition at line 82 of file dca-txop.cc.

References ns3::DcaTxop::GotCts(), and m_txop.

Here is the call graph for this function:

virtual void ns3::DcaTxop::TransmissionListener::MissedAck ( void  )

inlinevirtual

ns3::MacLow did not receive an expected ACK within AckTimeout.

Implements ns3::MacLowTransmissionListener.

Definition at line 94 of file dca-txop.cc.

References m_txop, and ns3::DcaTxop::MissedAck().

Here is the call graph for this function:

virtual void ns3::DcaTxop::TransmissionListener::MissedCts ( void  )

inlinevirtual

ns3::MacLow did not receive an expected CTS within CtsTimeout.

Implements ns3::MacLowTransmissionListener.

Definition at line 86 of file dca-txop.cc.

References m_txop, and ns3::DcaTxop::MissedCts().

Here is the call graph for this function:

virtual void ns3::DcaTxop::TransmissionListener::StartNext ( void  )

inlinevirtual

Invoked when ns3::MacLow wants to start a new transmission as configured by MacLowTransmissionParameters::EnableNextData. The listener is expected to call again MacLow::StartTransmission with the "next" data to send.

Implements ns3::MacLowTransmissionListener.

Definition at line 98 of file dca-txop.cc.

References m_txop, and ns3::DcaTxop::StartNext().

Here is the call graph for this function:

Member Data Documentation

DcaTxop* ns3::DcaTxop::TransmissionListener::m_txop

private

Definition at line 108 of file dca-txop.cc.

Referenced by Cancel(), GotAck(), GotCts(), MissedAck(), MissedCts(), and StartNext().

---

The documentation for this class was generated from the following file:

• src/wifi/model/dca-txop.cc
