ns3::LteEnbPhySapProvider Class Reference

#include <lte-enb-phy-sap.h>

Inheritance diagram for ns3::LteEnbPhySapProvider:

Public Member Functions
virtual	~LteEnbPhySapProvider ()
virtual uint8_t	GetMacChTtiDelay ()=0
	Get the delay from MAC to Channel expressed in TTIs.
virtual void	SendIdealControlMessage (Ptr< IdealControlMessage > msg)=0
	Send SendIdealControlMessage (PDCCH map, CQI feedbacks) using the ideal control channel.
virtual void	SendMacPdu (Ptr< Packet > p)=0
	Send the MAC PDU to the channel.
virtual void	SetBandwidth (uint8_t ulBandwidth, uint8_t dlBandwidth)=0
virtual void	SetCellId (uint16_t cellId)=0
virtual void	SetTransmissionMode (uint16_t rnti, uint8_t txMode)=0

Detailed Description

Service Access Point (SAP) offered by the eNB-PHY to the eNB-MAC

This is the PHY SAP Provider, i.e., the part of the SAP that contains the PHY methods called by the MAC

Definition at line 39 of file lte-enb-phy-sap.h.

Constructor & Destructor Documentation

ns3::LteEnbPhySapProvider::~LteEnbPhySapProvider ( )

virtual

Definition at line 28 of file lte-enb-phy-sap.cc.

Member Function Documentation

virtual uint8_t ns3::LteEnbPhySapProvider::GetMacChTtiDelay ( )

pure virtual

Get the delay from MAC to Channel expressed in TTIs.

Implemented in ns3::EnbMemberLteEnbPhySapProvider.

Referenced by ns3::LteEnbMac::DoConfigureMac().

Here is the caller graph for this function:

virtual void ns3::LteEnbPhySapProvider::SendIdealControlMessage ( Ptr< IdealControlMessage >  msg )

pure virtual

Send SendIdealControlMessage (PDCCH map, CQI feedbacks) using the ideal control channel.

Parameters

msg	the Ideal Control Message to send

Implemented in ns3::EnbMemberLteEnbPhySapProvider.

Referenced by ns3::LteEnbMac::DoSchedDlConfigInd(), and ns3::LteEnbMac::DoSchedUlConfigInd().

Here is the caller graph for this function:

virtual void ns3::LteEnbPhySapProvider::SendMacPdu ( Ptr< Packet >  p )

pure virtual

Send the MAC PDU to the channel.

Parameters

p	the MAC PDU to send

Returns

true if

Implemented in ns3::EnbMemberLteEnbPhySapProvider.

Referenced by ns3::LteEnbMac::DoTransmitPdu().

Here is the caller graph for this function:

virtual void ns3::LteEnbPhySapProvider::SetBandwidth ( uint8_t  ulBandwidth, uint8_t  dlBandwidth  )

pure virtual

Parameters

ulBandwidth	the UL bandwidth in RB
dlBandwidth	the DL bandwidth in RB

Implemented in ns3::EnbMemberLteEnbPhySapProvider.

virtual void ns3::LteEnbPhySapProvider::SetCellId ( uint16_t  cellId )

pure virtual

Parameters

cellId

the Cell Identifier

Implemented in ns3::EnbMemberLteEnbPhySapProvider.

virtual void ns3::LteEnbPhySapProvider::SetTransmissionMode ( uint16_t  rnti, uint8_t  txMode  )

pure virtual

Parameters

rnti	the RNTI of the user
txMode	the transmissionMode of the user

Implemented in ns3::EnbMemberLteEnbPhySapProvider.

Referenced by ns3::LteEnbMac::DoRrcUpdateConfigurationReq().

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/lte/model/lte-enb-phy-sap.h
• src/lte/model/lte-enb-phy-sap.cc
