#include <spectrum-error-model.h>

Inheritance diagram for ns3::ShannonSpectrumErrorModel:

Collaboration diagram for ns3::ShannonSpectrumErrorModel:

Public Member Functions
void	EvaluateChunk (const SpectrumValue &sinr, Time duration)
bool	IsRxCorrect ()
void	StartRx (Ptr< const Packet > p)
Public Member Functions inherited from ns3::SpectrumErrorModel
virtual	~SpectrumErrorModel ()
Public Member Functions inherited from ns3::Object
	Object ()
virtual	~Object ()
void	AggregateObject (Ptr< Object > other)
void	Dispose (void)
AggregateIterator	GetAggregateIterator (void) const
virtual TypeId	GetInstanceTypeId (void) const
template<typename T >
Ptr< T >	GetObject (void) const
template<typename T >
Ptr< T >	GetObject (TypeId tid) const
void	Start (void)
Public Member Functions inherited from ns3::SimpleRefCount< Object, ObjectBase, ObjectDeleter >
	SimpleRefCount ()
	SimpleRefCount (const SimpleRefCount &o)
uint32_t	GetReferenceCount (void) const
SimpleRefCount &	operator= (const SimpleRefCount &o)
void	Ref (void) const
void	Unref (void) const
Public Member Functions inherited from ns3::ObjectBase
virtual	~ObjectBase ()
void	GetAttribute (std::string name, AttributeValue &value) const
bool	GetAttributeFailSafe (std::string name, AttributeValue &attribute) const
void	SetAttribute (std::string name, const AttributeValue &value)
bool	SetAttributeFailSafe (std::string name, const AttributeValue &value)
bool	TraceConnect (std::string name, std::string context, const CallbackBase &cb)
bool	TraceConnectWithoutContext (std::string name, const CallbackBase &cb)
bool	TraceDisconnect (std::string name, std::string context, const CallbackBase &cb)
bool	TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb)

Protected Member Functions
virtual void	DoDispose ()

Private Attributes
uint32_t	m_bytes
uint32_t	m_deliverableBytes

Additional Inherited Members
Static Public Member Functions inherited from ns3::Object
static TypeId	GetTypeId (void)
	This method returns the TypeId associated to ns3::Object.

Detailed Description

This class implements the error model described in this paper: N. Baldo and M. Miozzo, "Spectrum-aware Channel and PHY layer modeling for ns3", in Proceedings of International Workshop on Network Simulation Tools (NSTOOLS 2009), 19 October 2009, Pisa (Italy).

Definition at line 57 of file spectrum-error-model.h.

Member Function Documentation

void ns3::ShannonSpectrumErrorModel::DoDispose ( void )

protectedvirtual

This method is called by Object::Dispose or by the object's destructor, whichever comes first.

Subclasses are expected to implement their real destruction code in an overriden version of this method and chain up to their parent's implementation once they are done. i.e., for simplicity, the destructor of every subclass should be empty and its content should be moved to the associated DoDispose method.

It is safe to call GetObject from within this method.

Reimplemented from ns3::Object.

Definition at line 35 of file spectrum-error-model.cc.

References NS_LOG_FUNCTION.
