a position model for which the current position does not change once it has been set and until it is set again explicitely to a new value. More...
#include <static-mobility-model.h>
Public Member Functions | |
| StaticMobilityModel () | |
Static Public Member Functions | |
| static TypeId | GetTypeId (void) |
| This method returns the TypeId associated to ns3::StaticMobilityModel. | |
Private Member Functions | |
| virtual Vector | DoGetPosition (void) const |
| virtual void | DoSetPosition (const Vector &position) |
| virtual Vector | DoGetVelocity (void) const |
Detailed Description
a position model for which the current position does not change once it has been set and until it is set again explicitely to a new value.
Constructor & Destructor Documentation
| ns3::StaticMobilityModel::StaticMobilityModel | ( | ) |
Create a position located at coordinates (0,0,0)
Member Function Documentation
| virtual Vector ns3::StaticMobilityModel::DoGetPosition | ( | void | ) | const [private, virtual] |
- Returns:
- the current position.
Concrete subclasses of this base class must implement this method.
Implements ns3::MobilityModel.
| virtual Vector ns3::StaticMobilityModel::DoGetVelocity | ( | void | ) | const [private, virtual] |
- Returns:
- the current velocity.
Concrete subclasses of this base class must implement this method.
Implements ns3::MobilityModel.
| virtual void ns3::StaticMobilityModel::DoSetPosition | ( | const Vector & | position | ) | [private, virtual] |
- Parameters:
-
position the position to set.
Concrete subclasses of this base class must implement this method.
Implements ns3::MobilityModel.
| static TypeId ns3::StaticMobilityModel::GetTypeId | ( | void | ) | [static] |
This method returns the TypeId associated to ns3::StaticMobilityModel.
This object is accessible through the following paths with Config::Set and Config::Connect:
- /NodeList/[i]/$ns3MobilityModel/$ns3StaticMobilityModel
No Attributes defined for this type.
Attributes defined in parent class ns3::MobilityModel:
-
Position: The current position of the mobility model.
- Set with class: VectorValue
- Underlying type: Vector
- Flags: write read
-
Velocity: The current velocity of the mobility model.
- Set with class: VectorValue
- Underlying type: Vector
- Flags: read
No TraceSources defined for this type.
TraceSources defined in parent class ns3::MobilityModel:
- CourseChange: The value of the position and/or velocity vector changed
Reimplemented from ns3::MobilityModel.
The documentation for this class was generated from the following files:
- src/mobility/static-mobility-model.h
- doc/introspected-doxygen.h
