Public Member Functions | Static Public Member Functions | Private Member Functions

ns3::StaticSpeedMobilityModel Class Reference

a position model for which the current speed does not change once it has been set and until it is set again explicitely to a new value. More...

#include <static-speed-mobility-model.h>

Inheritance diagram for ns3::StaticSpeedMobilityModel:
Inheritance graph
[legend]
Collaboration diagram for ns3::StaticSpeedMobilityModel:
Collaboration graph
[legend]

List of all members.

Public Member Functions

 StaticSpeedMobilityModel ()
void SetSpeed (const Vector &speed)

Static Public Member Functions

static TypeId GetTypeId (void)
 This method returns the TypeId associated to ns3::StaticSpeedMobilityModel.

Private Member Functions

virtual Vector DoGetPosition (void) const
virtual void DoSetPosition (const Vector &position)
virtual Vector DoGetVelocity (void) const

Detailed Description

a position model for which the current speed does not change once it has been set and until it is set again explicitely to a new value.


Constructor & Destructor Documentation

ns3::StaticSpeedMobilityModel::StaticSpeedMobilityModel (  )

Create position located at coordinates (0,0,0) with speed (0,0,0).


Member Function Documentation

virtual Vector ns3::StaticSpeedMobilityModel::DoGetPosition ( void   )  const [private, virtual]
Returns:
the current position.

Concrete subclasses of this base class must implement this method.

Implements ns3::MobilityModel.

virtual Vector ns3::StaticSpeedMobilityModel::DoGetVelocity ( void   )  const [private, virtual]
Returns:
the current velocity.

Concrete subclasses of this base class must implement this method.

Implements ns3::MobilityModel.

virtual void ns3::StaticSpeedMobilityModel::DoSetPosition ( const Vector position  )  [private, virtual]
Parameters:
position the position to set.

Concrete subclasses of this base class must implement this method.

Implements ns3::MobilityModel.

static TypeId ns3::StaticSpeedMobilityModel::GetTypeId ( void   )  [static]

This method returns the TypeId associated to ns3::StaticSpeedMobilityModel.

This object is accessible through the following paths with Config::Set and Config::Connect:

  • /NodeList/[i]/$ns3MobilityModel/$ns3StaticSpeedMobilityModel

No Attributes defined for this type.
Attributes defined in parent class ns3::MobilityModel:

  • Position: The current position of the mobility model.
  • Velocity: The current velocity of the mobility model.

No TraceSources defined for this type.
TraceSources defined in parent class ns3::MobilityModel:

  • CourseChange: The value of the position and/or velocity vector changed

Reimplemented from ns3::MobilityModel.

void ns3::StaticSpeedMobilityModel::SetSpeed ( const Vector speed  )
Parameters:
speed the new speed to set.

Set the current speed now to (dx,dy,dz) Unit is meters/s


The documentation for this class was generated from the following files:
