ns3::EpcX2HandoverPreparationFailureHeader Class Reference

Doxygen introspection did not find any typical Config paths. More...

#include <epc-x2-header.h>

+ Inheritance diagram for ns3::EpcX2HandoverPreparationFailureHeader:
+ Collaboration diagram for ns3::EpcX2HandoverPreparationFailureHeader:

Public Member Functions

 EpcX2HandoverPreparationFailureHeader ()

virtual ~EpcX2HandoverPreparationFailureHeader ()

virtual uint32_t Deserialize (Buffer::Iterator start)

uint16_t GetCause () const

uint16_t GetCriticalityDiagnostics () const

virtual TypeId GetInstanceTypeId (void) const

uint32_t GetLengthOfIes () const

uint32_t GetNumberOfIes () const

uint16_t GetOldEnbUeX2apId () const

virtual uint32_t GetSerializedSize (void) const

virtual void Print (std::ostream &os) const

virtual void Serialize (Buffer::Iterator start) const

void SetCause (uint16_t cause)

void SetCriticalityDiagnostics (uint16_t criticalityDiagnostics)

void SetOldEnbUeX2apId (uint16_t x2apId)

- Public Member Functions inherited from ns3::Header
virtual ~Header ()

- Public Member Functions inherited from ns3::ObjectBase
virtual ~ObjectBase ()
 Virtual destructor. More...

void GetAttribute (std::string name, AttributeValue &value) const

bool GetAttributeFailSafe (std::string name, AttributeValue &attribute) const

void SetAttribute (std::string name, const AttributeValue &value)

bool SetAttributeFailSafe (std::string name, const AttributeValue &value)

bool TraceConnect (std::string name, std::string context, const CallbackBase &cb)

bool TraceConnectWithoutContext (std::string name, const CallbackBase &cb)

bool TraceDisconnect (std::string name, std::string context, const CallbackBase &cb)

bool TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb)


Static Public Member Functions

static TypeId GetTypeId (void)

- Static Public Member Functions inherited from ns3::Header
static TypeId GetTypeId (void)
 Get the type ID. More...

- Static Public Member Functions inherited from ns3::Chunk
static TypeId GetTypeId (void)
 Get the type ID. More...

- Static Public Member Functions inherited from ns3::ObjectBase
static TypeId GetTypeId (void)
 Get the type ID. More...


Private Attributes

uint16_t m_cause

uint16_t m_criticalityDiagnostics

uint32_t m_headerLength

uint32_t m_numberOfIes

uint16_t m_oldEnbUeX2apId


Additional Inherited Members

- Protected Member Functions inherited from ns3::ObjectBase
void ConstructSelf (const AttributeConstructionList &attributes)

virtual void NotifyConstructionCompleted (void)
 This method is invoked once all member attributes have been initialized. More...


Detailed Description

Doxygen introspection did not find any typical Config paths.


No Attributes are defined for this type.
No TraceSources are defined for this type.

Definition at line 172 of file epc-x2-header.h.

Constructor & Destructor Documentation

ns3::EpcX2HandoverPreparationFailureHeader::EpcX2HandoverPreparationFailureHeader ( )

Definition at line 663 of file epc-x2-header.cc.

ns3::EpcX2HandoverPreparationFailureHeader::~EpcX2HandoverPreparationFailureHeader ( )
virtual

Member Function Documentation

uint32_t ns3::EpcX2HandoverPreparationFailureHeader::Deserialize ( Buffer::Iterator  start)
virtual
Parameters
startan iterator which points to where the header should written.
Returns
the number of bytes read.

This method is used by Packet::RemoveHeader to re-create a header from the byte buffer of a packet. The data read is expected to match bit-for-bit the representation of this header in real networks.

Implements ns3::Header.

Definition at line 714 of file epc-x2-header.cc.

References GetSerializedSize(), m_cause, m_criticalityDiagnostics, m_headerLength, m_numberOfIes, m_oldEnbUeX2apId, ns3::Buffer::Iterator::ReadNtohU16(), and visualizer.core::start().

+ Here is the call graph for this function:

uint16_t ns3::EpcX2HandoverPreparationFailureHeader::GetCause ( ) const

Definition at line 749 of file epc-x2-header.cc.

References m_cause.

Referenced by ns3::EpcX2::RecvFromX2cSocket().

+ Here is the caller graph for this function:

uint16_t ns3::EpcX2HandoverPreparationFailureHeader::GetCriticalityDiagnostics ( ) const

Definition at line 761 of file epc-x2-header.cc.

References m_criticalityDiagnostics.

Referenced by ns3::EpcX2::RecvFromX2cSocket().

+ Here is the caller graph for this function:

TypeId ns3::EpcX2HandoverPreparationFailureHeader::GetInstanceTypeId ( void  ) const
virtual
Returns
the TypeId associated to the most-derived type of this instance.

This method is typically implemented by ns3::Object::GetInstanceTypeId but some classes which derive from ns3::ObjectBase directly have to implement it themselves.

Implements ns3::ObjectBase.

Definition at line 692 of file epc-x2-header.cc.

References GetTypeId().

+ Here is the call graph for this function:

uint32_t ns3::EpcX2HandoverPreparationFailureHeader::GetLengthOfIes ( ) const

Definition at line 773 of file epc-x2-header.cc.

References m_headerLength.

Referenced by ns3::EpcX2::DoSendHandoverPreparationFailure().

+ Here is the caller graph for this function:

uint32_t ns3::EpcX2HandoverPreparationFailureHeader::GetNumberOfIes ( ) const

Definition at line 779 of file epc-x2-header.cc.

References m_numberOfIes.

Referenced by ns3::EpcX2::DoSendHandoverPreparationFailure().

+ Here is the caller graph for this function:

uint16_t ns3::EpcX2HandoverPreparationFailureHeader::GetOldEnbUeX2apId ( ) const

Definition at line 737 of file epc-x2-header.cc.

References m_oldEnbUeX2apId.

Referenced by ns3::EpcX2::RecvFromX2cSocket().

+ Here is the caller graph for this function:

uint32_t ns3::EpcX2HandoverPreparationFailureHeader::GetSerializedSize ( void  ) const
virtual
Returns
the expected size of the header.

This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. This method should return the number of bytes which are needed to store the full header data by Serialize.

Implements ns3::Header.

Definition at line 698 of file epc-x2-header.cc.

References m_headerLength.

Referenced by Deserialize().

+ Here is the caller graph for this function:

TypeId ns3::EpcX2HandoverPreparationFailureHeader::GetTypeId ( void  )
static

Definition at line 682 of file epc-x2-header.cc.

References ns3::TypeId::SetParent().

Referenced by GetInstanceTypeId().

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void ns3::EpcX2HandoverPreparationFailureHeader::Print ( std::ostream &  os) const
virtual
Parameters
osoutput stream This method is used by Packet::Print to print the content of a trailer as ascii data to a c++ output stream. Although the trailer is free to format its output as it wishes, it is recommended to follow a few rules to integrate with the packet pretty printer: start with flags, small field values located between a pair of parens. Values should be separated by whitespace. Follow the parens with the important fields, separated by whitespace. i.e.: (field1 val1 field2 val2 field3 val3) field4 val4 field5 val5

Implements ns3::Header.

Definition at line 729 of file epc-x2-header.cc.

References m_cause, m_criticalityDiagnostics, and m_oldEnbUeX2apId.

void ns3::EpcX2HandoverPreparationFailureHeader::Serialize ( Buffer::Iterator  start) const
virtual
Parameters
startan iterator which points to where the header should be written.

This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. The data written is expected to match bit-for-bit the representation of this header in a real network.

Implements ns3::Header.

Definition at line 704 of file epc-x2-header.cc.

References m_cause, m_criticalityDiagnostics, m_oldEnbUeX2apId, visualizer.core::start(), and ns3::Buffer::Iterator::WriteHtonU16().

+ Here is the call graph for this function:

void ns3::EpcX2HandoverPreparationFailureHeader::SetCause ( uint16_t  cause)

Definition at line 755 of file epc-x2-header.cc.

References m_cause.

Referenced by ns3::EpcX2::DoSendHandoverPreparationFailure().

+ Here is the caller graph for this function:

void ns3::EpcX2HandoverPreparationFailureHeader::SetCriticalityDiagnostics ( uint16_t  criticalityDiagnostics)

Definition at line 767 of file epc-x2-header.cc.

References m_criticalityDiagnostics.

Referenced by ns3::EpcX2::DoSendHandoverPreparationFailure().

+ Here is the caller graph for this function:

void ns3::EpcX2HandoverPreparationFailureHeader::SetOldEnbUeX2apId ( uint16_t  x2apId)

Definition at line 743 of file epc-x2-header.cc.

References m_oldEnbUeX2apId.

Referenced by ns3::EpcX2::DoSendHandoverPreparationFailure().

+ Here is the caller graph for this function:

Member Data Documentation

uint16_t ns3::EpcX2HandoverPreparationFailureHeader::m_cause
private
uint16_t ns3::EpcX2HandoverPreparationFailureHeader::m_criticalityDiagnostics
private
uint32_t ns3::EpcX2HandoverPreparationFailureHeader::m_headerLength
private
uint32_t ns3::EpcX2HandoverPreparationFailureHeader::m_numberOfIes
private
uint16_t ns3::EpcX2HandoverPreparationFailureHeader::m_oldEnbUeX2apId
private

The documentation for this class was generated from the following files:
