ns3::FfMacCschedSapProvider Class Reference

Provides the CSCHED SAP. More...

#include <ff-mac-csched-sap.h>

Inheritance diagram for ns3::FfMacCschedSapProvider:

Classes
struct	CschedCellConfigReqParameters
	Parameters of the API primitives. More...
struct	CschedLcConfigReqParameters
	Parameters of the CSCHED_LC_CONFIG_REQ primitive. More...
struct	CschedLcReleaseReqParameters
	Parameters of the CSCHED_LC_RELEASE_REQ primitive. More...
struct	CschedUeConfigReqParameters
	Parameters of the CSCHED_UE_CONFIG_REQ primitive. More...
struct	CschedUeReleaseReqParameters
	Parameters of the CSCHED_UE_RELEASE_REQ primitive. More...

Public Member Functions
virtual	~FfMacCschedSapProvider ()
virtual void	CschedCellConfigReq (const struct CschedCellConfigReqParameters &params)=0
	CSCHED_CELL_CONFIG_REQ. More...
virtual void	CschedLcConfigReq (const struct CschedLcConfigReqParameters &params)=0
virtual void	CschedLcReleaseReq (const struct CschedLcReleaseReqParameters &params)=0
virtual void	CschedUeConfigReq (const struct CschedUeConfigReqParameters &params)=0
virtual void	CschedUeReleaseReq (const struct CschedUeReleaseReqParameters &params)=0

Detailed Description

Provides the CSCHED SAP.

This abstract class defines the MAC Scheduler interface specified in the Femto Forum Technical Document:

• LTE MAC Scheduler Interface Specification v1.11

The Technical Document contains a detailed description of the API. The documentation of this class refers to sections of this Technical Document.

You can found an example of the implementation of this interface in the SampleFfMacCschedSapProvider and SampleFfMacCschedSapuser classes

Definition at line 45 of file ff-mac-csched-sap.h.

Constructor & Destructor Documentation

ns3::FfMacCschedSapProvider::~FfMacCschedSapProvider ( )

virtual

Definition at line 25 of file ff-mac-csched-sap.cc.

Member Function Documentation

virtual void ns3::FfMacCschedSapProvider::CschedCellConfigReq ( const struct CschedCellConfigReqParameters &  params )

pure virtual

CSCHED_CELL_CONFIG_REQ.

Implemented in ns3::CqaSchedulerMemberCschedSapProvider, ns3::PssSchedulerMemberCschedSapProvider, ns3::RrSchedulerMemberCschedSapProvider, ns3::FdTbfqSchedulerMemberCschedSapProvider, ns3::TdTbfqSchedulerMemberCschedSapProvider, ns3::FdBetSchedulerMemberCschedSapProvider, ns3::FdMtSchedulerMemberCschedSapProvider, ns3::TdBetSchedulerMemberCschedSapProvider, ns3::TdMtSchedulerMemberCschedSapProvider, ns3::TtaSchedulerMemberCschedSapProvider, and ns3::PfSchedulerMemberCschedSapProvider.

Referenced by ns3::LteEnbMac::DoConfigureMac().

Here is the caller graph for this function:

virtual void ns3::FfMacCschedSapProvider::CschedLcConfigReq ( const struct CschedLcConfigReqParameters &  params )

pure virtual

Implemented in ns3::CqaSchedulerMemberCschedSapProvider, ns3::PssSchedulerMemberCschedSapProvider, ns3::RrSchedulerMemberCschedSapProvider, ns3::FdTbfqSchedulerMemberCschedSapProvider, ns3::TdTbfqSchedulerMemberCschedSapProvider, ns3::FdBetSchedulerMemberCschedSapProvider, ns3::FdMtSchedulerMemberCschedSapProvider, ns3::TdBetSchedulerMemberCschedSapProvider, ns3::TdMtSchedulerMemberCschedSapProvider, ns3::TtaSchedulerMemberCschedSapProvider, and ns3::PfSchedulerMemberCschedSapProvider.

Referenced by ns3::LteEnbMac::DoAddLc().

Here is the caller graph for this function:

virtual void ns3::FfMacCschedSapProvider::CschedLcReleaseReq ( const struct CschedLcReleaseReqParameters &  params )

pure virtual

Implemented in ns3::CqaSchedulerMemberCschedSapProvider, ns3::PssSchedulerMemberCschedSapProvider, ns3::RrSchedulerMemberCschedSapProvider, ns3::FdTbfqSchedulerMemberCschedSapProvider, ns3::TdTbfqSchedulerMemberCschedSapProvider, ns3::FdBetSchedulerMemberCschedSapProvider, ns3::FdMtSchedulerMemberCschedSapProvider, ns3::TdBetSchedulerMemberCschedSapProvider, ns3::TdMtSchedulerMemberCschedSapProvider, ns3::TtaSchedulerMemberCschedSapProvider, and ns3::PfSchedulerMemberCschedSapProvider.

virtual void ns3::FfMacCschedSapProvider::CschedUeConfigReq ( const struct CschedUeConfigReqParameters &  params )

pure virtual

Implemented in ns3::CqaSchedulerMemberCschedSapProvider, ns3::PssSchedulerMemberCschedSapProvider, ns3::RrSchedulerMemberCschedSapProvider, ns3::FdTbfqSchedulerMemberCschedSapProvider, ns3::TdTbfqSchedulerMemberCschedSapProvider, ns3::FdBetSchedulerMemberCschedSapProvider, ns3::FdMtSchedulerMemberCschedSapProvider, ns3::TdBetSchedulerMemberCschedSapProvider, ns3::TdMtSchedulerMemberCschedSapProvider, ns3::TtaSchedulerMemberCschedSapProvider, and ns3::PfSchedulerMemberCschedSapProvider.

Referenced by ns3::LteEnbMac::DoAddUe(), and ns3::LteEnbMac::DoUeUpdateConfigurationReq().

Here is the caller graph for this function:

virtual void ns3::FfMacCschedSapProvider::CschedUeReleaseReq ( const struct CschedUeReleaseReqParameters &  params )

pure virtual

Implemented in ns3::CqaSchedulerMemberCschedSapProvider, ns3::PssSchedulerMemberCschedSapProvider, ns3::RrSchedulerMemberCschedSapProvider, ns3::FdTbfqSchedulerMemberCschedSapProvider, ns3::TdTbfqSchedulerMemberCschedSapProvider, ns3::FdBetSchedulerMemberCschedSapProvider, ns3::FdMtSchedulerMemberCschedSapProvider, ns3::TdBetSchedulerMemberCschedSapProvider, ns3::TdMtSchedulerMemberCschedSapProvider, ns3::TtaSchedulerMemberCschedSapProvider, and ns3::PfSchedulerMemberCschedSapProvider.

Referenced by ns3::LteEnbMac::DoRemoveUe().

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/lte/model/ff-mac-csched-sap.h
• src/lte/model/ff-mac-csched-sap.cc
