Struct interface to NSC stack. More...

#include <sim_interface.h>

Public Member Functions
virtual	~INetStack ()

virtual void	add_default_gateway (const char *addr)=0
	Add a default gateway to the interface. More...

virtual void	buffer_size (int size)=0
	Set the buffer size. More...

virtual int	cmd (const char *)
	Simple interface to support sending any textual command to a stack. More...

virtual int	get_hz ()=0
	Get the timer_interrupt frequency. More...

virtual int	get_id ()=0
	Returns the internal id of the stack instance. More...

virtual const char *	get_name ()=0
	Return a short one-word name of the stack. More...

virtual bool	get_var (const char var, char result, int result_len)
	Optional function to get variables for this stack. More...

virtual void	if_attach (const char addr, const char mask, int mtu)=0
	Attach an interface to the stack. More...

virtual void	if_receive_packet (int if_id, const void *data, int datalen)=0
	Deliver complete packet to the NSC network stack. More...

virtual void	if_send_finish (int if_id)=0
	Signal the completion of send procedure to the NSC network stack. More...

virtual void	if_send_packet (const void *data, int datalen)=0
	Send complete packet to the NSC network stack. More...

virtual void	increment_ticks ()=0
	Increment the time ticks. More...

virtual void	init (int hz)=0
	Initialize the stack. More...

virtual struct INetStreamSocket *	new_sctp_socket ()
	Create a new SCTP socket. More...

virtual struct INetStreamSocket *	new_tcp_socket ()
	Create a new TCP socket. More...

virtual struct INetDatagramSocket *	new_udp_socket ()
	Create a new UDP socket. More...

virtual void	set_diagnostic (int level)
	Set the level of debugging or diagnostic information to print out. More...

virtual bool	set_var (const char var, const char val)
	Optional function to set variables for this stack. More...

virtual void	show_config ()
	Show the NSC configuration. More...

virtual int	sysctl (const char sysctl_name, void oldval, size_t oldlenp, void newval, size_t newlen)
	use sysctl to modify system parameters More...

virtual int	sysctl_get (const char name, char value, size_t len)
	Get system parameters using sysctl. More...

virtual int	sysctl_getnum (size_t idx, char *name, size_t len)
	Tell the cradle code to put the name of sysctl number 'idx' into name[]. More...

virtual int	sysctl_set (const char name, const char value)
	Set system parameters using sysctl. More...

virtual void	timer_interrupt ()=0
	The stack timer_interrupt function. More...

Detailed Description

Struct interface to NSC stack.

Definition at line 31 of file sim_interface.h.

Constructor & Destructor Documentation

virtual INetStack::~INetStack ( )

inlinevirtual

Definition at line 33 of file sim_interface.h.

Member Function Documentation

virtual void INetStack::add_default_gateway ( const char * addr )

pure virtual

Add a default gateway to the interface.

Parameters

addr	gateway address

Referenced by ns3::NscTcpL4Protocol::AddInterface().

Here is the caller graph for this function:

virtual void INetStack::buffer_size ( int size )

pure virtual

Set the buffer size.

virtual int INetStack::cmd ( const char * )

inlinevirtual

Simple interface to support sending any textual command to a stack.

Returns: 0 on success

Definition at line 245 of file sim_interface.h.

virtual int INetStack::get_hz ( )

pure virtual

Get the timer_interrupt frequency.

This is used so the simulator can call the stack timer_interrupt function the correct amount of times per second. For example, lwip has a hz of 10, which it returns here to say that it's timer_interrupt should be called 10 times a second. FreeBSD uses 100, as does Linux 2.4, while Linux 2.6 uses 1000. (This is often configurable in the kernel in question, also.)

Returns: frequency

Referenced by ns3::NscTcpL4Protocol::SetNode().

Here is the caller graph for this function:

virtual int INetStack::get_id ( )

pure virtual

Returns the internal id of the stack instance.

Purely for debugging/diagnostic purposes.

Returns: internal stack id

virtual const char* INetStack::get_name ( )

pure virtual

Return a short one-word name of the stack.

Should return a short one-word name of the stack. Eg. Linux 2.4.x -> linux24, FreeBSD 5.x -> freebsd5. This can be used to identify output from a stack, for example a packet trace file.

Returns: short one-word name of the stack

Referenced by ns3::Ns3NscStack::GetInstanceTypeId().

Here is the caller graph for this function:

virtual bool INetStack::get_var	(	const char *	var,
		char *	result,
		int	result_len
	)

inlinevirtual

Optional function to get variables for this stack.

Parameters

var	the variable
result	the result
result_len	result length

Returns: true on success

Definition at line 214 of file sim_interface.h.

virtual void INetStack::if_attach	(	const char *	addr,
		const char *	mask,
		int	mtu
	)

pure virtual

Attach an interface to the stack.

Parameters

addr	address
mask	network mask
mtu	MTU

Referenced by ns3::NscTcpL4Protocol::AddInterface().

Here is the caller graph for this function:

virtual void INetStack::if_receive_packet	(	int	if_id,
		const void *	data,
		int	datalen
	)

pure virtual

Deliver complete packet to the NSC network stack.

Parameters

if_id	interface ID
data	data
datalen	data length

Referenced by ns3::NscTcpL4Protocol::Receive().

Here is the caller graph for this function:

virtual void INetStack::if_send_finish ( int if_id )

pure virtual

Signal the completion of send procedure to the NSC network stack.

Parameters

if_id interface ID

Referenced by ns3::NscTcpL4Protocol::send_callback().

Here is the caller graph for this function:

virtual void INetStack::if_send_packet	(	const void *	data,
		int	datalen
	)

pure virtual

Send complete packet to the NSC network stack.

Parameters

data	data
datalen	data length

virtual void INetStack::increment_ticks ( )

pure virtual

Increment the time ticks.

Referenced by ns3::NscTcpL4Protocol::SoftInterrupt().

Here is the caller graph for this function:

virtual void INetStack::init ( int hz )

pure virtual

Initialize the stack.

Parameters

hz	timer_interrupt frequency

Referenced by ns3::NscTcpL4Protocol::SetNode().

Here is the caller graph for this function:

virtual struct INetStreamSocket* INetStack::new_sctp_socket ( )

inlinevirtual

Create a new SCTP socket.

Definition at line 130 of file sim_interface.h.

virtual struct INetStreamSocket* INetStack::new_tcp_socket ( )

inlinevirtual

Create a new TCP socket.

Definition at line 126 of file sim_interface.h.

virtual struct INetDatagramSocket* INetStack::new_udp_socket ( )

inlinevirtual

Create a new UDP socket.

Definition at line 122 of file sim_interface.h.

virtual void INetStack::set_diagnostic ( int level )

inlinevirtual

Set the level of debugging or diagnostic information to print out.

This normally means kernel messages printed out during initialisation but may also include extra debugging messages that are part of NSC.

Parameters

level debugging/diagnostic level

Definition at line 238 of file sim_interface.h.

virtual bool INetStack::set_var	(	const char *	var,
		const char *	val
	)

inlinevirtual

Optional function to set variables for this stack.

Parameters

var	the variable
val	the new value

Returns: true on success

Definition at line 225 of file sim_interface.h.

virtual void INetStack::show_config ( )

inlinevirtual

Show the NSC configuration.

Definition at line 202 of file sim_interface.h.

virtual int INetStack::sysctl	(	const char *	sysctl_name,
		void *	oldval,
		size_t *	oldlenp,
		void *	newval,
		size_t	newlen
	)

inlinevirtual

use sysctl to modify system parameters

Parameters

sysctl_name	name of the parameter to modify
oldval	old value
oldlenp	old value length
newval	new value
newlen	new value length

Returns

Definition at line 143 of file sim_interface.h.

virtual int INetStack::sysctl_get	(	const char *	name,
		char *	value,
		size_t	len
	)

inlinevirtual

Get system parameters using sysctl.

Parameters

name	name of the parameter to modify
value	value
len	value length

Returns: length of the string in value, i.e. retval > len: 'output truncated'.

Definition at line 174 of file sim_interface.h.

Referenced by ns3::Ns3NscStack::Get(), and ns3::Ns3NscStack::GetInstanceTypeId().

Here is the caller graph for this function:

virtual int INetStack::sysctl_getnum	(	size_t	idx,
		char *	name,
		size_t	len
	)

inlinevirtual

Tell the cradle code to put the name of sysctl number 'idx' into name[].

The idea is that this can be used to get a list of all available sysctls:

char buf[256]
for (i=0; sysctl_getnum(i, buf, sizeof(buf)) > 0 ;i++)
   puts(buf);

Parameters

idx	index
name	sysctl name
len	sysctl length

Returns: -1 if idx is out of range and the length of the sysctl name otherwise.

Definition at line 194 of file sim_interface.h.

Referenced by ns3::Ns3NscStack::GetInstanceTypeId().

Here is the caller graph for this function:

virtual int INetStack::sysctl_set	(	const char *	name,
		const char *	value
	)

inlinevirtual

Set system parameters using sysctl.

Parameters

name	name of the parameter to modify
value	new value

Returns

Definition at line 159 of file sim_interface.h.

Referenced by ns3::Ns3NscStack::Set().

Here is the caller graph for this function:

virtual void INetStack::timer_interrupt ( )

pure virtual

The stack timer_interrupt function.

Referenced by ns3::NscTcpL4Protocol::SoftInterrupt().

Here is the caller graph for this function:

The documentation for this struct was generated from the following file:

src/internet/model/sim_interface.h
