The propagation loss is fixed for each pair of nodes and doesn't depend on their actual positions. More...
#include "propagation-loss-model.h"
Public Member Functions | |
MatrixPropagationLossModel () | |
MatrixPropagationLossModel (const MatrixPropagationLossModel &)=delete | |
~MatrixPropagationLossModel () override | |
MatrixPropagationLossModel & | operator= (const MatrixPropagationLossModel &)=delete |
void | SetDefaultLoss (double defaultLoss) |
Set the default propagation loss (in dB, positive) to be used, infinity if not set. | |
void | SetLoss (Ptr< MobilityModel > a, Ptr< MobilityModel > b, double loss, bool symmetric=true) |
Set loss (in dB, positive) between pair of ns-3 objects (typically, nodes). | |
![]() | |
PropagationLossModel () | |
PropagationLossModel (const PropagationLossModel &)=delete | |
~PropagationLossModel () override | |
int64_t | AssignStreams (int64_t stream) |
If this loss model uses objects of type RandomVariableStream, set the stream numbers to the integers starting with the offset 'stream'. | |
double | CalcRxPower (double txPowerDbm, Ptr< MobilityModel > a, Ptr< MobilityModel > b) const |
Returns the Rx Power taking into account all the PropagationLossModel(s) chained to the current one. | |
Ptr< PropagationLossModel > | GetNext () |
Gets the next PropagationLossModel in the chain of loss models that act on the signal. | |
PropagationLossModel & | operator= (const PropagationLossModel &)=delete |
void | SetNext (Ptr< PropagationLossModel > next) |
Enables a chain of loss models to act on the signal. | |
![]() | |
Object () | |
Constructor. | |
~Object () override | |
Destructor. | |
void | AggregateObject (Ptr< Object > other) |
Aggregate two Objects together. | |
void | Dispose () |
Dispose of this Object. | |
AggregateIterator | GetAggregateIterator () const |
Get an iterator to the Objects aggregated to this one. | |
TypeId | GetInstanceTypeId () const override |
Get the most derived TypeId for this Object. | |
template<typename T > | |
Ptr< T > | GetObject () const |
Get a pointer to the requested aggregated Object. | |
template<> | |
Ptr< Object > | GetObject () const |
Specialization of () for objects of type ns3::Object. | |
template<typename T > | |
Ptr< T > | GetObject (TypeId tid) const |
Get a pointer to the requested aggregated Object by TypeId. | |
template<> | |
Ptr< Object > | GetObject (TypeId tid) const |
Specialization of (TypeId tid) for objects of type ns3::Object. | |
void | Initialize () |
Invoke DoInitialize on all Objects aggregated to this one. | |
bool | IsInitialized () const |
Check if the object has been initialized. | |
![]() | |
SimpleRefCount () | |
Default constructor. | |
SimpleRefCount (const SimpleRefCount &o) | |
Copy constructor. | |
uint32_t | GetReferenceCount () const |
Get the reference count of the object. | |
SimpleRefCount & | operator= (const SimpleRefCount &o) |
Assignment operator. | |
void | Ref () const |
Increment the reference count. | |
void | Unref () const |
Decrement the reference count. | |
![]() | |
virtual | ~ObjectBase () |
Virtual destructor. | |
void | GetAttribute (std::string name, AttributeValue &value) const |
Get the value of an attribute, raising fatal errors if unsuccessful. | |
bool | GetAttributeFailSafe (std::string name, AttributeValue &value) const |
Get the value of an attribute without raising errors. | |
virtual TypeId | GetInstanceTypeId () const =0 |
Get the most derived TypeId for this Object. | |
void | SetAttribute (std::string name, const AttributeValue &value) |
Set a single attribute, raising fatal errors if unsuccessful. | |
bool | SetAttributeFailSafe (std::string name, const AttributeValue &value) |
Set a single attribute without raising errors. | |
bool | TraceConnect (std::string name, std::string context, const CallbackBase &cb) |
Connect a TraceSource to a Callback with a context. | |
bool | TraceConnectWithoutContext (std::string name, const CallbackBase &cb) |
Connect a TraceSource to a Callback without a context. | |
bool | TraceDisconnect (std::string name, std::string context, const CallbackBase &cb) |
Disconnect from a TraceSource a Callback previously connected with a context. | |
bool | TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb) |
Disconnect from a TraceSource a Callback previously connected without a context. | |
Static Public Member Functions | |
static TypeId | GetTypeId () |
Get the type ID. | |
![]() | |
static TypeId | GetTypeId () |
Get the type ID. | |
![]() | |
static TypeId | GetTypeId () |
Register this type. | |
![]() | |
static TypeId | GetTypeId () |
Get the type ID. | |
Private Types | |
typedef std::pair< Ptr< MobilityModel >, Ptr< MobilityModel > > | MobilityPair |
Typedef: Mobility models pair. | |
Private Member Functions | |
int64_t | DoAssignStreams (int64_t stream) override |
Assign a fixed random variable stream number to the random variables used by this model. | |
double | DoCalcRxPower (double txPowerDbm, Ptr< MobilityModel > a, Ptr< MobilityModel > b) const override |
PropagationLossModel. | |
Private Attributes | |
double | m_default |
default loss | |
std::map< MobilityPair, double > | m_loss |
Propagation loss between pair of nodes. | |
Additional Inherited Members | |
virtual int64_t | DoAssignStreams (int64_t stream)=0 |
Assign a fixed random variable stream number to the random variables used by this model. | |
![]() | |
Object (const Object &o) | |
Copy an Object. | |
virtual void | DoDispose () |
Destructor implementation. | |
virtual void | DoInitialize () |
Initialize() implementation. | |
virtual void | NotifyNewAggregate () |
Notify all Objects aggregated to this one of a new Object being aggregated. | |
![]() | |
void | ConstructSelf (const AttributeConstructionList &attributes) |
Complete construction of ObjectBase; invoked by derived classes. | |
virtual void | NotifyConstructionCompleted () |
Notifier called once the ObjectBase is fully constructed. | |
![]() | |
static TypeId | GetObjectIid () |
Ensure the TypeId for ObjectBase gets fully configured to anchor the inheritance tree properly. | |
The propagation loss is fixed for each pair of nodes and doesn't depend on their actual positions.
This is supposed to be used by synthetic tests. Note that by default propagation loss is assumed to be symmetric.
ns3::MatrixPropagationLossModel is accessible through the following paths with Config::Set and Config::Connect:
No TraceSources are defined for this type.
Size of this type is 96 bytes (on a 64-bit architecture).
Definition at line 702 of file propagation-loss-model.h.
|
private |
Typedef: Mobility models pair.
Definition at line 745 of file propagation-loss-model.h.
ns3::MatrixPropagationLossModel::MatrixPropagationLossModel | ( | ) |
Definition at line 847 of file propagation-loss-model.cc.
|
override |
Definition at line 853 of file propagation-loss-model.cc.
|
delete |
|
overrideprivatevirtual |
Assign a fixed random variable stream number to the random variables used by this model.
Subclasses must implement this; those not using random variables can return zero.
stream | first stream index to use |
Implements ns3::PropagationLossModel.
Definition at line 907 of file propagation-loss-model.cc.
|
overrideprivatevirtual |
txPowerDbm | current transmission power (in dBm) |
a | the mobility model of the source |
b | the mobility model of the destination |
Implements ns3::PropagationLossModel.
Definition at line 890 of file propagation-loss-model.cc.
|
static |
Get the type ID.
Definition at line 832 of file propagation-loss-model.cc.
References m_default, ns3::MakeDoubleAccessor(), and ns3::TypeId::SetParent().
|
delete |
void ns3::MatrixPropagationLossModel::SetDefaultLoss | ( | double | defaultLoss | ) |
Set the default propagation loss (in dB, positive) to be used, infinity if not set.
defaultLoss | the default proagation loss |
Definition at line 858 of file propagation-loss-model.cc.
References m_default.
Referenced by MatrixPropagationLossModelTestCase::DoRun().
void ns3::MatrixPropagationLossModel::SetLoss | ( | Ptr< MobilityModel > | a, |
Ptr< MobilityModel > | b, | ||
double | loss, | ||
bool | symmetric = true |
||
) |
Set loss (in dB, positive) between pair of ns-3 objects (typically, nodes).
a | ma Source mobility model |
b | mb Destination mobility model |
loss | a -> b path loss, positive in dB |
symmetric | If true (default), both a->b and b->a paths will be affected |
Definition at line 864 of file propagation-loss-model.cc.
References m_loss, NS_ASSERT, and SetLoss().
Referenced by MatrixPropagationLossModelTestCase::DoRun(), and SetLoss().
|
private |
default loss
Definition at line 742 of file propagation-loss-model.h.
Referenced by DoCalcRxPower(), GetTypeId(), and SetDefaultLoss().
|
private |
Propagation loss between pair of nodes.
Definition at line 747 of file propagation-loss-model.h.
Referenced by DoCalcRxPower(), and SetLoss().
