Data structure to contain the information that defines a group. More...
#include "minstrel-ht-wifi-manager.h"
Public Attributes | |
uint16_t | chWidth |
channel width (MHz) | |
uint16_t | gi |
guard interval duration (nanoseconds) | |
bool | isSupported |
flag whether group is supported | |
TxTime | ratesFirstMpduTxTimeTable |
rates MPDU transmit time table | |
TxTime | ratesTxTimeTable |
rates transmit time table | |
uint8_t | streams |
number of spatial streams | |
McsGroupType | type |
identifies the group, | |
Data structure to contain the information that defines a group.
It also contains the transmission times for all the MCS in the group. A group is a collection of MCS defined by the number of spatial streams, if it uses or not Short Guard Interval, and the channel width used.
Definition at line 81 of file minstrel-ht-wifi-manager.h.
uint16_t ns3::McsGroup::chWidth |
channel width (MHz)
Definition at line 85 of file minstrel-ht-wifi-manager.h.
Referenced by ns3::MinstrelHtWifiManager::DoGetDataTxVector(), ns3::MinstrelHtWifiManager::StatsDump(), and ns3::MinstrelHtWifiManager::UpdateRateAfterAllowedWidth().
uint16_t ns3::McsGroup::gi |
guard interval duration (nanoseconds)
Definition at line 84 of file minstrel-ht-wifi-manager.h.
Referenced by ns3::MinstrelHtWifiManager::DoGetDataTxVector(), ns3::MinstrelHtWifiManager::StatsDump(), and ns3::MinstrelHtWifiManager::UpdateRateAfterAllowedWidth().
bool ns3::McsGroup::isSupported |
flag whether group is supported
Definition at line 87 of file minstrel-ht-wifi-manager.h.
Referenced by ns3::MinstrelHtWifiManager::UpdateRateAfterAllowedWidth().
TxTime ns3::McsGroup::ratesFirstMpduTxTimeTable |
rates MPDU transmit time table
Definition at line 91 of file minstrel-ht-wifi-manager.h.
TxTime ns3::McsGroup::ratesTxTimeTable |
rates transmit time table
Definition at line 90 of file minstrel-ht-wifi-manager.h.
uint8_t ns3::McsGroup::streams |
number of spatial streams
Definition at line 83 of file minstrel-ht-wifi-manager.h.
Referenced by ns3::MinstrelHtWifiManager::DoGetDataTxVector(), ns3::MinstrelHtWifiManager::StatsDump(), and ns3::MinstrelHtWifiManager::UpdateRateAfterAllowedWidth().
McsGroupType ns3::McsGroup::type |
identifies the group,
Definition at line 86 of file minstrel-ht-wifi-manager.h.
Referenced by ns3::MinstrelHtWifiManager::DoGetDataTxVector(), ns3::MinstrelHtWifiManager::StatsDump(), and ns3::MinstrelHtWifiManager::UpdateRateAfterAllowedWidth().
