ns3::NodeList Class Reference

the list of simulation nodes. More...

#include "node-list.h"

Public Types

typedef std::vector< Ptr< Node > >::const_iterator Iterator
 Node container iterator.


Static Public Member Functions

static uint32_t Add (Ptr< Node > node)

static Iterator Begin ()

static Iterator End ()

static uint32_t GetNNodes ()

static Ptr< NodeGetNode (uint32_t n)


Detailed Description

the list of simulation nodes.

Every Node created is automatically added to this list.

Definition at line 40 of file node-list.h.

Member Typedef Documentation

◆ Iterator

typedef std::vector<Ptr<Node>>::const_iterator ns3::NodeList::Iterator

Node container iterator.

Definition at line 44 of file node-list.h.

Member Function Documentation

◆ Add()

uint32_t ns3::NodeList::Add ( Ptr< Node node)
static
Parameters
nodenode to add
Returns
index of node in list.

This method is called automatically from Node::Node so the user has little reason to call it himself.

Definition at line 230 of file node-list.cc.

References ns3::NodeListPriv::Get(), and NS_LOG_FUNCTION.

Referenced by ns3::Node::Construct().

+ Here is the call graph for this function:
+ Here is the caller graph for this function:

◆ Begin()

NodeList::Iterator ns3::NodeList::Begin ( )
static
Returns
a C++ iterator located at the beginning of this list.

Definition at line 237 of file node-list.cc.

References ns3::NodeListPriv::Get(), and NS_LOG_FUNCTION_NOARGS.

Referenced by ns3::GlobalRouteManagerImpl::BuildGlobalRoutingDatabase(), ns3::NixVectorRouting< T >::BuildIpAddressToNodeMap(), ns3::AnimationInterface::ConnectLte(), ns3::GlobalRouteManagerImpl::DeleteGlobalRoutes(), ns3::LteEnbRrcProtocolIdeal::DoSendSystemInformation(), ns3::LteEnbRrcProtocolReal::DoSendSystemInformation(), EmlsrOperationsTestBase::DoSetup(), ns3::AnimationInterface::EnableIpv4L3ProtocolCounters(), ns3::AnimationInterface::EnableQueueCounters(), ns3::AnimationInterface::EnableWifiMacCounters(), ns3::AnimationInterface::EnableWifiPhyCounters(), ns3::GlobalRouteManagerImpl::FindOutgoingInterfaceId(), ns3::NixVectorRouting< T >::FlushGlobalNixRoutingCache(), ns3::NodeContainer::GetGlobal(), ns3::AnimationInterface::GetMovedNodes(), ns3::GlobalRouteManagerImpl::InitializeRoutes(), ns3::Ns2MobilityHelper::Install(), ns3::FlowMonitorHelper::InstallAll(), PrintGnuplottableEnbListToFile(), PrintGnuplottableUeListToFile(), PrintUePosition(), ns3::LteUeRrcProtocolIdeal::SetEnbRrcSapProvider(), ns3::LteUeRrcProtocolReal::SetEnbRrcSapProvider(), ns3::GlobalRouteManagerImpl::SPFAddASExternal(), ns3::GlobalRouteManagerImpl::SPFIntraAddRouter(), ns3::GlobalRouteManagerImpl::SPFIntraAddStub(), ns3::GlobalRouteManagerImpl::SPFIntraAddTransit(), MultiLinkTxTest::StartTraffic(), MultiLinkMuTxTest::StartTraffic(), ReleaseSeqNoAfterCtsTimeoutTest::StartTraffic(), ns3::AnimationInterface::TrackIpv4L3ProtocolCounters(), ns3::AnimationInterface::TrackIpv4Route(), ns3::AnimationInterface::TrackQueueCounters(), ns3::AnimationInterface::TrackWifiMacCounters(), ns3::AnimationInterface::TrackWifiPhyCounters(), ns3::AnimationInterface::WriteLinkProperties(), ns3::AnimationInterface::WriteNodeColors(), ns3::AnimationInterface::WriteNodeEnergies(), ns3::AnimationInterface::WriteNodes(), and ns3::AnimationInterface::WriteNodeSizes().

+ Here is the call graph for this function:
+ Here is the caller graph for this function:

◆ End()

NodeList::Iterator ns3::NodeList::End ( )
static
Returns
a C++ iterator located at the end of this list.

Definition at line 244 of file node-list.cc.

References ns3::NodeListPriv::Get(), and NS_LOG_FUNCTION_NOARGS.

Referenced by ns3::GlobalRouteManagerImpl::BuildGlobalRoutingDatabase(), ns3::NixVectorRouting< T >::BuildIpAddressToNodeMap(), ns3::AnimationInterface::ConnectLte(), ns3::GlobalRouteManagerImpl::DeleteGlobalRoutes(), ns3::LteEnbRrcProtocolIdeal::DoSendSystemInformation(), ns3::LteEnbRrcProtocolReal::DoSendSystemInformation(), EmlsrOperationsTestBase::DoSetup(), ns3::AnimationInterface::EnableIpv4L3ProtocolCounters(), ns3::AnimationInterface::EnableQueueCounters(), ns3::AnimationInterface::EnableWifiMacCounters(), ns3::AnimationInterface::EnableWifiPhyCounters(), ns3::GlobalRouteManagerImpl::FindOutgoingInterfaceId(), ns3::NixVectorRouting< T >::FlushGlobalNixRoutingCache(), ns3::NodeContainer::GetGlobal(), ns3::AnimationInterface::GetMovedNodes(), ns3::GlobalRouteManagerImpl::InitializeRoutes(), ns3::Ns2MobilityHelper::Install(), ns3::FlowMonitorHelper::InstallAll(), PrintGnuplottableEnbListToFile(), PrintGnuplottableUeListToFile(), PrintUePosition(), ns3::LteUeRrcProtocolIdeal::SetEnbRrcSapProvider(), ns3::LteUeRrcProtocolReal::SetEnbRrcSapProvider(), ns3::GlobalRouteManagerImpl::SPFAddASExternal(), ns3::GlobalRouteManagerImpl::SPFIntraAddRouter(), ns3::GlobalRouteManagerImpl::SPFIntraAddStub(), ns3::GlobalRouteManagerImpl::SPFIntraAddTransit(), MultiLinkTxTest::StartTraffic(), MultiLinkMuTxTest::StartTraffic(), ReleaseSeqNoAfterCtsTimeoutTest::StartTraffic(), ns3::AnimationInterface::TrackIpv4L3ProtocolCounters(), ns3::AnimationInterface::TrackIpv4Route(), ns3::AnimationInterface::TrackQueueCounters(), ns3::AnimationInterface::TrackWifiMacCounters(), ns3::AnimationInterface::TrackWifiPhyCounters(), ns3::AnimationInterface::WriteLinkProperties(), ns3::AnimationInterface::WriteNodeColors(), ns3::AnimationInterface::WriteNodeEnergies(), ns3::AnimationInterface::WriteNodes(), and ns3::AnimationInterface::WriteNodeSizes().

+ Here is the call graph for this function:
+ Here is the caller graph for this function:

◆ GetNNodes()

◆ GetNode()

Ptr< Node > ns3::NodeList::GetNode ( uint32_t  n)
static
Parameters
nindex of requested node.
Returns
the Node associated to index n.

Definition at line 251 of file node-list.cc.

References ns3::NodeListPriv::Get(), and NS_LOG_FUNCTION.

Referenced by ContextToMac(), ns3::PyViz::FindNetDeviceStatistics(), ns3::NeighborCacheHelper::FlushAutoGenerated(), ns3::dsr::DsrOptions::GetIDfromIP(), ns3::dsr::DsrRouting::GetIDfromIP(), ns3::dsr::DsrRouting::GetIPfromID(), ns3::dsr::DsrRouting::GetIPfromMAC(), ns3::AnimationInterface::GetIpv4Address(), ns3::AnimationInterface::GetIpv4Addresses(), ns3::AnimationInterface::GetIpv6Address(), ns3::AnimationInterface::GetIpv6Addresses(), ns3::dsr::DsrRouting::GetNetDeviceFromContext(), ns3::GlobalRoutingLSA::GetNode(), ns3::AnimationInterface::GetNodeFromContext(), ns3::dsr::DsrOptions::GetNodeWithAddress(), ns3::dsr::DsrRouting::GetNodeWithAddress(), DsdvManetExample::InstallApplications(), ns3::Ipv4RoutingHelper::PrintNeighborCacheAllAt(), ns3::Ipv6RoutingHelper::PrintNeighborCacheAllAt(), ns3::Ipv4RoutingHelper::PrintNeighborCacheAllEvery(), ns3::Ipv6RoutingHelper::PrintNeighborCacheAllEvery(), ns3::Ipv4RoutingHelper::PrintRoutingTableAllAt(), ns3::Ipv6RoutingHelper::PrintRoutingTableAllAt(), ns3::Ipv4RoutingHelper::PrintRoutingTableAllEvery(), ns3::Ipv6RoutingHelper::PrintRoutingTableAllEvery(), ns3::dsr::DsrOptionSR::Process(), ns3::GrantedTimeWindowMpiInterface::ReceiveMessages(), ns3::NullMessageMpiInterface::ReceiveMessages(), ns3::AnimationInterface::RecursiveIpv4RoutePathSearch(), ns3::GrantedTimeWindowMpiInterface::SendPacket(), ns3::NullMessageMpiInterface::SendPacket(), ns3::PyViz::TraceDevQueueDrop(), ns3::PyViz::TraceNetDevRxCommon(), ns3::PyViz::TraceNetDevTxCommon(), ns3::AnimationInterface::TrackIpv4RoutePaths(), ns3::AnimationInterface::UpdateNodeColor(), ns3::AnimationInterface::UpdateNodeDescription(), ns3::AnimationInterface::WifiPhyRxBeginTrace(), and ns3::AnimationInterface::WriteNodeEnergies().

+ Here is the call graph for this function:
+ Here is the caller graph for this function:

The documentation for this class was generated from the following files:
