WifiBarBlockAck specifies that a BlockAckReq is sent to solicit a Block Ack response. More...
#include "wifi-acknowledgment.h"
Public Member Functions | |
WifiBarBlockAck () | |
bool | CheckQosAckPolicy (Mac48Address receiver, uint8_t tid, WifiMacHeader::QosAckPolicy ackPolicy) const override |
Check whether the given QoS Ack policy can be used for the MPDUs addressed to the given receiver and belonging to the given TID. | |
std::unique_ptr< WifiAcknowledgment > | Copy () const override |
Clone this object. | |
void | Print (std::ostream &os) const override |
Print the object contents. | |
Public Member Functions inherited from ns3::WifiAcknowledgment | |
WifiAcknowledgment (Method m) | |
Constructor. | |
virtual | ~WifiAcknowledgment () |
virtual std::unique_ptr< WifiAcknowledgment > | Copy () const =0 |
Clone this object. | |
WifiMacHeader::QosAckPolicy | GetQosAckPolicy (Mac48Address receiver, uint8_t tid) const |
Get the QoS Ack policy to use for the MPDUs addressed to the given receiver and belonging to the given TID. | |
virtual void | Print (std::ostream &os) const =0 |
Print the object contents. | |
void | SetQosAckPolicy (Mac48Address receiver, uint8_t tid, WifiMacHeader::QosAckPolicy ackPolicy) |
Set the QoS Ack policy to use for the MPDUs addressed to the given receiver and belonging to the given TID. | |
Public Attributes | |
BlockAckReqType | barType |
BlockAckReq type. | |
BlockAckType | baType |
BlockAck type. | |
WifiTxVector | blockAckReqTxVector |
BlockAckReq TXVECTOR. | |
WifiTxVector | blockAckTxVector |
BlockAck TXVECTOR. | |
Public Attributes inherited from ns3::WifiAcknowledgment | |
Time | acknowledgmentTime |
time required by the acknowledgment method | |
const Method | method |
acknowledgment method | |
Additional Inherited Members | |
Public Types inherited from ns3::WifiAcknowledgment | |
enum | Method { NONE = 0 , NORMAL_ACK , BLOCK_ACK , BAR_BLOCK_ACK , DL_MU_BAR_BA_SEQUENCE , DL_MU_TF_MU_BAR , DL_MU_AGGREGATE_TF , UL_MU_MULTI_STA_BA , ACK_AFTER_TB_PPDU } |
Available acknowledgment methods. More... | |
WifiBarBlockAck specifies that a BlockAckReq is sent to solicit a Block Ack response.
Definition at line 183 of file wifi-acknowledgment.h.
ns3::WifiBarBlockAck::WifiBarBlockAck | ( | ) |
Definition at line 152 of file wifi-acknowledgment.cc.
|
overridevirtual |
Check whether the given QoS Ack policy can be used for the MPDUs addressed to the given receiver and belonging to the given TID.
receiver | the MAC address of the receiver |
tid | the TID |
ackPolicy | the QoS Ack policy to use |
Implements ns3::WifiAcknowledgment.
Definition at line 164 of file wifi-acknowledgment.cc.
References ns3::WifiMacHeader::BLOCK_ACK.
|
overridevirtual |
Clone this object.
Implements ns3::WifiAcknowledgment.
Definition at line 158 of file wifi-acknowledgment.cc.
|
overridevirtual |
Print the object contents.
os | output stream in which the data should be printed. |
Implements ns3::WifiAcknowledgment.
Definition at line 172 of file wifi-acknowledgment.cc.
BlockAckReqType ns3::WifiBarBlockAck::barType |
BlockAckReq type.
Definition at line 195 of file wifi-acknowledgment.h.
Referenced by ns3::HtFrameExchangeManager::CalculateAcknowledgmentTime().
BlockAckType ns3::WifiBarBlockAck::baType |
BlockAck type.
Definition at line 196 of file wifi-acknowledgment.h.
Referenced by ns3::HtFrameExchangeManager::CalculateAcknowledgmentTime().
WifiTxVector ns3::WifiBarBlockAck::blockAckReqTxVector |
BlockAckReq TXVECTOR.
Definition at line 193 of file wifi-acknowledgment.h.
Referenced by ns3::HtFrameExchangeManager::CalculateAcknowledgmentTime().
WifiTxVector ns3::WifiBarBlockAck::blockAckTxVector |
BlockAck TXVECTOR.
Definition at line 194 of file wifi-acknowledgment.h.
Referenced by ns3::HtFrameExchangeManager::CalculateAcknowledgmentTime().
