#include "ns3/command-line.h"
#include "ns3/config.h"
#include "ns3/internet-stack-helper.h"
#include "ns3/ipv4-address-helper.h"
#include "ns3/mobility-helper.h"
#include "ns3/multi-model-spectrum-channel.h"
#include "ns3/non-communicating-net-device.h"
#include "ns3/on-off-helper.h"
#include "ns3/packet-sink-helper.h"
#include "ns3/packet-sink.h"
#include "ns3/propagation-loss-model.h"
#include "ns3/spectrum-wifi-helper.h"
#include "ns3/ssid.h"
#include "ns3/string.h"
#include "ns3/udp-client-server-helper.h"
#include "ns3/waveform-generator-helper.h"
#include "ns3/waveform-generator.h"
#include "ns3/wifi-net-device.h"
#include "ns3/yans-wifi-channel.h"
#include "ns3/yans-wifi-helper.h"
#include <iomanip>

Include dependency graph for wifi-spectrum-per-interference.cc:

Classes
class	static_SpectrumModelWifi5180MHz_initializer
	Initializer for a static spectrum model centered around 5180 MHz. More...

class	static_SpectrumModelWifi5190MHz_initializer
	Initializer for a static spectrum model centered around 5190 MHz. More...

Functions
void	MonitorSniffRx (Ptr< const Packet > packet, uint16_t channelFreqMhz, WifiTxVector txVector, MpduInfo aMpdu, SignalNoiseDbm signalNoise, uint16_t staId)
	Monitor sniffer Rx trace.

Variables
double	g_noiseDbmAvg
	Average noise power [dBm].

uint32_t	g_samples
	Number of samples.

double	g_signalDbmAvg
	Average signal power [dBm].

Ptr< SpectrumModel >	SpectrumModelWifi5180MHz
	Spectrum model at 5180 MHz.

Ptr< SpectrumModel >	SpectrumModelWifi5190MHz
	Spectrum model at 5190 MHz.

static_SpectrumModelWifi5180MHz_initializer	static_SpectrumModelWifi5180MHz_initializer_instance
	Static instance to initizlize the spectrum model around 5180 MHz.

static_SpectrumModelWifi5190MHz_initializer	static_SpectrumModelWifi5190MHz_initializer_instance
	Static instance to initizlize the spectrum model around 5190 MHz.

Detailed Description

Usage

$ ./ns3 run "wifi-spectrum-per-interference [Program Options]"

Program Options

--simulationTime: Simulation time in seconds [10]
--udp: UDP if set to 1, TCP otherwise [true]
--distance: meters separation between nodes [50]
--index: restrict index to single value between 0 and 31 [256]
--wifiType: select ns3::SpectrumWifiPhy or ns3::YansWifiPhy [ns3::SpectrumWifiPhy]
--errorModelType: select ns3::NistErrorRateModel or ns3::YansErrorRateModel [ns3::NistErrorRateModel]
--enablePcap: enable pcap output [false]
--waveformPower: Waveform power (linear W) [0]

Definition in file wifi-spectrum-per-interference.cc.

Function Documentation

◆ MonitorSniffRx()

void MonitorSniffRx	(	Ptr< const Packet >	packet,
		uint16_t	channelFreqMhz,
		WifiTxVector	txVector,
		MpduInfo	aMpdu,
		SignalNoiseDbm	signalNoise,
		uint16_t	staId
	)

Monitor sniffer Rx trace.

Parameters

packet	The sensed packet.
channelFreqMhz	The channel frequency [MHz].
txVector	The Tx vector.
aMpdu	The aMPDU.
signalNoise	The signal and noise dBm.
staId	The STA ID.
