wifi-mlo-test.cc File Reference

#include "ns3/ap-wifi-mac.h"
#include "ns3/config.h"
#include "ns3/eht-configuration.h"
#include "ns3/frame-exchange-manager.h"
#include "ns3/log.h"
#include "ns3/mgt-headers.h"
#include "ns3/mobility-helper.h"
#include "ns3/multi-link-element.h"
#include "ns3/multi-model-spectrum-channel.h"
#include "ns3/node-list.h"
#include "ns3/packet-socket-client.h"
#include "ns3/packet-socket-helper.h"
#include "ns3/packet-socket-server.h"
#include "ns3/packet.h"
#include "ns3/pointer.h"
#include "ns3/qos-utils.h"
#include "ns3/rng-seed-manager.h"
#include "ns3/rr-multi-user-scheduler.h"
#include "ns3/spectrum-wifi-helper.h"
#include "ns3/spectrum-wifi-phy.h"
#include "ns3/sta-wifi-mac.h"
#include "ns3/string.h"
#include "ns3/test.h"
#include "ns3/wifi-acknowledgment.h"
#include "ns3/wifi-assoc-manager.h"
#include "ns3/wifi-mac-header.h"
#include "ns3/wifi-mac-queue.h"
#include "ns3/wifi-net-device.h"
#include "ns3/wifi-protection.h"
#include "ns3/wifi-psdu.h"
#include <algorithm>
#include <array>
#include <iomanip>
#include <optional>
#include <sstream>
#include <tuple>
#include <vector>

Include dependency graph for wifi-mlo-test.cc:

Go to the source code of this file.

Classes
struct	MultiLinkOperationsTestBase::BaseParams
	Configuration parameters common to all subclasses. More...
struct	MultiLinkOperationsTestBase::FrameInfo
	Information about transmitted frames. More...
class	GetRnrLinkInfoTest
	Test the implementation of WifiAssocManager::GetNextAffiliatedAp(), which searches a given RNR element for APs affiliated to the same AP MLD as the reporting AP that sent the frame containing the element. More...
class	MldSwapLinksTest
	Test the WifiMac::SwapLinks() method. More...
class	MultiLinkMuTxTest
	Test data transmission between MLDs using OFDMA MU transmissions. More...
class	MultiLinkOperationsTestBase
	Base class for Multi-Link Operations tests. More...
class	MultiLinkSetupTest
	Multi-Link Discovery & Setup test. More...
class	MultiLinkTxTest
	Test data transmission between two MLDs. More...
class	ReleaseSeqNoAfterCtsTimeoutTest
	Test release of sequence numbers upon CTS timeout in multi-link operations. More...
class	MldSwapLinksTest::TestWifiMac
	Test WifiMac subclass used to access the SwapLinks method. More...
class	WifiMultiLinkOperationsTestSuite
	wifi 11be MLD Test Suite More...

Enumerations
enum class	WifiBaEnabled : uint8_t { NO = 0 , YES }
	Block Ack agreement enabled/disabled. More...
enum class	WifiMuTrafficPattern : uint8_t { DL_MU_BAR_BA_SEQUENCE = 0 , DL_MU_MU_BAR , DL_MU_AGGR_MU_BAR , UL_MU }
	Tested MU traffic patterns. More...
enum class	WifiTrafficPattern : uint8_t {   STA_TO_STA = 0 , STA_TO_AP , AP_TO_STA , AP_TO_BCAST ,   STA_TO_BCAST }
	Tested traffic patterns. More...
enum class	WifiUseBarAfterMissedBa : uint8_t { NO = 0 , YES }
	Whether to send a BlockAckReq after a missed BlockAck. More...

Variables
static WifiMultiLinkOperationsTestSuite	g_wifiMultiLinkOperationsTestSuite
	the test suite

Enumeration Type Documentation

WifiBaEnabled

enum class WifiBaEnabled : uint8_t

strong

Block Ack agreement enabled/disabled.

Enumerator
NO
YES

Definition at line 1763 of file wifi-mlo-test.cc.

WifiMuTrafficPattern

enum class WifiMuTrafficPattern : uint8_t

strong

Tested MU traffic patterns.

Enumerator
DL_MU_BAR_BA_SEQUENCE
DL_MU_MU_BAR
DL_MU_AGGR_MU_BAR
UL_MU

Definition at line 2336 of file wifi-mlo-test.cc.

WifiTrafficPattern

enum class WifiTrafficPattern : uint8_t

strong

Tested traffic patterns.

Enumerator
STA_TO_STA
STA_TO_AP
AP_TO_STA
AP_TO_BCAST
STA_TO_BCAST

Definition at line 1751 of file wifi-mlo-test.cc.

WifiUseBarAfterMissedBa

enum class WifiUseBarAfterMissedBa : uint8_t

strong

Whether to send a BlockAckReq after a missed BlockAck.

Enumerator
NO
YES

Definition at line 1772 of file wifi-mlo-test.cc.

Variable Documentation

g_wifiMultiLinkOperationsTestSuite

WifiMultiLinkOperationsTestSuite g_wifiMultiLinkOperationsTestSuite

static

the test suite

Definition at line 3288 of file wifi-mlo-test.cc.
