Abstract Channel Base Class. More...
#include <channel.h>
Public Member Functions | |
| uint32_t | GetId (void) const |
| virtual uint32_t | GetNDevices (void) const =0 |
| virtual Ptr< NetDevice > | GetDevice (uint32_t i) const =0 |
Static Public Member Functions | |
| static TypeId | GetTypeId (void) |
| This method returns the TypeId associated to ns3::Channel. | |
Detailed Description
Abstract Channel Base Class.
A channel is a logical path over which information flows. The path can be as simple as a short piece of wire, or as complicated as space-time.
Subclasses must use Simulator::ScheduleWithContext to correctly update event contexts when scheduling an event from one node to another one.
Member Function Documentation
- Parameters:
-
i index of NetDevice to retrieve
- Returns:
- one of the NetDevices connected to this channel.
This method must be implemented by subclasses.
Implemented in ns3::BridgeChannel, ns3::CsmaChannel, ns3::PointToPointChannel, ns3::YansWifiChannel, and ns3::SimpleChannel.
| uint32_t ns3::Channel::GetId | ( | void | ) | const |
- Returns:
- the unique id of this channel
This unique id happens to be also the index of the Channel into the ChannelList.
| virtual uint32_t ns3::Channel::GetNDevices | ( | void | ) | const [pure virtual] |
- Returns:
- the number of NetDevices connected to this Channel.
This method must be implemented by subclasses.
Implemented in ns3::BridgeChannel, ns3::CsmaChannel, ns3::PointToPointChannel, ns3::YansWifiChannel, and ns3::SimpleChannel.
| static TypeId ns3::Channel::GetTypeId | ( | void | ) | [static] |
This method returns the TypeId associated to ns3::Channel.
Attributes defined for this type:
-
Id: The id (unique integer) of this Channel.
- Set with class: ns3::UintegerValue
- Underlying type: uint32_t 0:4294967295
- Flags: read
No TraceSources defined for this type.
Reimplemented from ns3::Object.
Reimplemented in ns3::BridgeChannel, ns3::CsmaChannel, ns3::PointToPointChannel, ns3::WifiChannel, ns3::YansWifiChannel, and ns3::SimpleChannel.
The documentation for this class was generated from the following files:
- src/node/channel.h
- doc/introspected-doxygen.h
