keep track of the state needed for a single DCF function.
More...
#include <dcf-manager.h>
List of all members.
Public Member Functions |
void | SetAifsn (uint32_t aifsn) |
void | SetCwMin (uint32_t minCw) |
void | SetCwMax (uint32_t maxCw) |
uint32_t | GetAifsn (void) const |
uint32_t | GetCwMin (void) const |
uint32_t | GetCwMax (void) const |
void | ResetCw (void) |
void | UpdateFailedCw (void) |
void | StartBackoffNow (uint32_t nSlots) |
uint32_t | GetCw (void) const |
bool | IsAccessRequested (void) const |
Friends |
class | DcfManager |
Detailed Description
keep track of the state needed for a single DCF function.
Multiple instances of a DcfState can be registered in a single DcfManager to implement 802.11e-style relative QoS. DcfState::SetAifsn and DcfState::SetCwBounds allow the user to control the relative QoS differentiation.
Member Function Documentation
uint32_t ns3::DcfState::GetCw |
( |
void |
|
) |
const |
- Returns:
- the current value of the CW variable. The initial value is minCW.
bool ns3::DcfState::IsAccessRequested |
( |
void |
|
) |
const |
- Returns:
- true if access has been requested for this DcfState and has not been granted already, false otherwise.
void ns3::DcfState::ResetCw |
( |
void |
|
) |
|
Update the value of the CW variable to take into account a transmission success or a transmission abort (stop transmission of a packet after the maximum number of retransmissions has been reached). By default, this resets the CW variable to minCW.
void ns3::DcfState::SetAifsn |
( |
uint32_t |
aifsn |
) |
|
- Parameters:
-
| aifsn | the number of slots which make up an AIFS for a specific DCF. a DIFS corresponds to an AIFSN = 2. |
Calling this method after DcfManager::Add has been called is not recommended.
void ns3::DcfState::StartBackoffNow |
( |
uint32_t |
nSlots |
) |
|
- Parameters:
-
| nSlots | the number of slots of the backoff. |
Start a backoff by initializing the backoff counter to the number of slots specified.
void ns3::DcfState::UpdateFailedCw |
( |
void |
|
) |
|
Update the value of the CW variable to take into account a transmission failure. By default, this triggers a doubling of CW (capped by maxCW).
The documentation for this class was generated from the following file:
- src/devices/wifi/dcf-manager.h
