Public Member Functions | |
| DlMap (void) | |
| This class implements DL-map ie as described by "IEEE Standard for
Local and metropolitan area networks Part 16: Air Interface for Fixed Broadband Wireless Access Systems" 8.2.1.8.1 Compressed DL-MAP, page 402. | |
| void | SetDcdCount (uint8_t dcdCount) |
| void | SetBaseStationId (Mac48Address baseStationID) |
| void | AddDlMapElement (OfdmDlMapIe dlMapElement) |
| uint8_t | GetDcdCount (void) const |
| Mac48Address | GetBaseStationId (void) const |
| std::list< OfdmDlMapIe > | GetDlMapElements (void) const |
| std::string | GetName (void) const |
| virtual TypeId | GetInstanceTypeId (void) const |
| void | Print (std::ostream &os) const |
| uint32_t | GetSerializedSize (void) const |
| void | Serialize (Buffer::Iterator start) const |
| uint32_t | Deserialize (Buffer::Iterator start) |
Static Public Member Functions | |
| static TypeId | GetTypeId (void) |
| This method returns the TypeId associated to ns3::DlMap. | |
Member Function Documentation
| uint32_t ns3::DlMap::Deserialize | ( | Buffer::Iterator | start | ) | [virtual] |
- Parameters:
-
start an iterator which points to where the header should written.
- Returns:
- the number of bytes read.
This method is used by Packet::RemoveHeader to re-create a header from the byte buffer of a packet. The data read is expected to match bit-for-bit the representation of this header in real networks.
Implements ns3::Header.
| virtual TypeId ns3::DlMap::GetInstanceTypeId | ( | void | ) | const [virtual] |
- Returns:
- the TypeId associated to the most-derived type of this instance.
This method is typically implemented by ns3::Object::GetInstanceTypeId but some classes which derive from ns3::ObjectBase directly have to implement it themselves.
Implements ns3::ObjectBase.
| uint32_t ns3::DlMap::GetSerializedSize | ( | void | ) | const [virtual] |
- Returns:
- the expected size of the header.
This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. This method should return the number of bytes which are needed to store the full header data by Serialize.
Implements ns3::Header.
| static TypeId ns3::DlMap::GetTypeId | ( | void | ) | [static] |
This method returns the TypeId associated to ns3::DlMap.
No Attributes defined for this type.
No TraceSources defined for this type.
Reimplemented from ns3::Header.
| void ns3::DlMap::Print | ( | std::ostream & | os | ) | const [virtual] |
- Parameters:
-
os output stream This method is used by Packet::Print to print the content of a trailer as ascii data to a c++ output stream. Although the trailer is free to format its output as it wishes, it is recommended to follow a few rules to integrate with the packet pretty printer: start with flags, small field values located between a pair of parens. Values should be separated by whitespace. Follow the parens with the important fields, separated by whitespace. i.e.: (field1 val1 field2 val2 field3 val3) field4 val4 field5 val5
Implements ns3::Header.
| void ns3::DlMap::Serialize | ( | Buffer::Iterator | start | ) | const [virtual] |
- Parameters:
-
start an iterator which points to where the header should be written.
This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. The data written is expected to match bit-for-bit the representation of this header in a real network.
Implements ns3::Header.
The documentation for this class was generated from the following files:
- src/devices/wimax/dl-mac-messages.h
- doc/introspected-doxygen.h
