#include <flow-probe.h>
Inheritance diagram for ns3::FlowProbe:
Collaboration diagram for ns3::FlowProbe:
Classes | |
| struct | FlowStats |
Public Types | |
|
typedef std::map< FlowId, FlowStats > | Stats |
Public Member Functions | |
| void | AddPacketStats (FlowId flowId, uint32_t packetSize, Time delayFromFirstProbe) |
| void | AddPacketDropStats (FlowId flowId, uint32_t packetSize, uint32_t reasonCode) |
| Stats | GetStats () const |
| void | SerializeToXmlStream (std::ostream &os, int indent, uint32_t index) const |
Protected Member Functions | |
| FlowProbe (Ptr< FlowMonitor > flowMonitor) | |
Protected Attributes | |
| Ptr< FlowMonitor > | m_flowMonitor |
| Stats | m_stats |
Detailed Description
The FlowProbe class is responsible for listening for packet events in a specific point of the simulated space, report those events to the global FlowMonitor, and collect its own flow statistics regarding only the packets that pass through that probe.
Member Function Documentation
| Stats ns3::FlowProbe::GetStats | ( | ) | const |
Get the partial flow statistics stored in this probe. With this information you can, for example, find out what is the delay from the first probe to this one.
The documentation for this class was generated from the following file:
- src/contrib/flow-monitor/flow-probe.h
