this class implements the Generic mac Header as described by IEEE Standard for Local and metropolitan area networks Part 16: Air Interface for Fixed Broadband Wireless Access Systems 6.3.2.1.1 Generic MAC header, page 36 More...
#include <wimax-mac-header.h>
Public Member Functions | |
void | SetEc (uint8_t ec) |
void | SetType (uint8_t type) |
void | SetCi (uint8_t ci) |
void | SetEks (uint8_t eks) |
void | SetLen (uint16_t len) |
void | SetCid (Cid cid) |
void | SetHcs (uint8_t hcs) |
void | SetHt (uint8_t HT) |
uint8_t | GetEc (void) const |
uint8_t | GetType (void) const |
uint8_t | GetCi (void) const |
uint8_t | GetEks (void) const |
uint16_t | GetLen (void) const |
Cid | GetCid (void) const |
uint8_t | GetHcs (void) const |
uint8_t | GetHt (void) const |
std::string | GetName (void) const |
virtual TypeId | GetInstanceTypeId (void) const |
void | Print (std::ostream &os) const |
uint32_t | GetSerializedSize (void) const |
void | Serialize (Buffer::Iterator start) const |
uint32_t | Deserialize (Buffer::Iterator start) |
bool | check_hcs (void) const |
Static Public Member Functions | |
static TypeId | GetTypeId (void) |
This method returns the TypeId associated to ns3::GenericMacHeader. |
this class implements the Generic mac Header as described by IEEE Standard for Local and metropolitan area networks Part 16: Air Interface for Fixed Broadband Wireless Access Systems 6.3.2.1.1 Generic MAC header, page 36
uint32_t ns3::GenericMacHeader::Deserialize | ( | Buffer::Iterator | start | ) | [virtual] |
start | an iterator which points to where the header should written. |
This method is used by Packet::RemoveHeader to re-create a header from the byte buffer of a packet. The data read is expected to match bit-for-bit the representation of this header in real networks.
Implements ns3::Header.
virtual TypeId ns3::GenericMacHeader::GetInstanceTypeId | ( | void | ) | const [virtual] |
This method is typically implemented by ns3::Object::GetInstanceTypeId but some classes which derive from ns3::ObjectBase directly have to implement it themselves.
Implements ns3::ObjectBase.
uint32_t ns3::GenericMacHeader::GetSerializedSize | ( | void | ) | const [virtual] |
This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. This method should return the number of bytes which are needed to store the full header data by Serialize.
Implements ns3::Header.
static TypeId ns3::GenericMacHeader::GetTypeId | ( | void | ) | [static] |
This method returns the TypeId associated to ns3::GenericMacHeader.
No Attributes defined for this type.
No TraceSources defined for this type.
Reimplemented from ns3::Header.
void ns3::GenericMacHeader::Print | ( | std::ostream & | os | ) | const [virtual] |
os | output stream This method is used by Packet::Print to print the content of a trailer as ascii data to a c++ output stream. Although the trailer is free to format its output as it wishes, it is recommended to follow a few rules to integrate with the packet pretty printer: start with flags, small field values located between a pair of parens. Values should be separated by whitespace. Follow the parens with the important fields, separated by whitespace. i.e.: (field1 val1 field2 val2 field3 val3) field4 val4 field5 val5 |
Implements ns3::Header.
void ns3::GenericMacHeader::Serialize | ( | Buffer::Iterator | start | ) | const [virtual] |
start | an iterator which points to where the header should be written. |
This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. The data written is expected to match bit-for-bit the representation of this header in a real network.
Implements ns3::Header.
