A layer between the sockets interface and IP.
More...
#include <tcp-l4-protocol.h>
List of all members.
Public Member Functions |
| TcpL4Protocol () |
| Constructor.
|
void | SetNode (Ptr< Node > node) |
virtual int | GetProtocolNumber (void) const |
Ptr< Socket > | CreateSocket (void) |
Ipv4EndPoint * | Allocate (void) |
Ipv4EndPoint * | Allocate (Ipv4Address address) |
Ipv4EndPoint * | Allocate (uint16_t port) |
Ipv4EndPoint * | Allocate (Ipv4Address address, uint16_t port) |
Ipv4EndPoint * | Allocate (Ipv4Address localAddress, uint16_t localPort, Ipv4Address peerAddress, uint16_t peerPort) |
void | DeAllocate (Ipv4EndPoint *endPoint) |
void | Send (Ptr< Packet > packet, Ipv4Address saddr, Ipv4Address daddr, uint16_t sport, uint16_t dport, Ptr< NetDevice > oif=0) |
| Send a packet via TCP.
|
virtual enum
Ipv4L4Protocol::RxStatus | Receive (Ptr< Packet > p, Ipv4Header const &header, Ptr< Ipv4Interface > incomingInterface) |
| Receive a packet up the protocol stack.
|
Static Public Member Functions |
static TypeId | GetTypeId (void) |
| This method returns the TypeId associated to ns3::TcpL4Protocol.
|
Static Public Attributes |
static const uint8_t | PROT_NUMBER |
Protected Member Functions |
virtual void | DoDispose (void) |
virtual void | NotifyNewAggregate () |
Friends |
class | TcpSocketImpl |
Detailed Description
A layer between the sockets interface and IP.
This class allocates "endpoint" objects (ns3::Ipv4EndPoint) for TCP, and SHOULD checksum packets its receives from the socket layer going down the stack , but currently checksumming is disabled. It also receives packets from IP, and forwards them up to the endpoints.
Member Function Documentation
Ptr<Socket> ns3::TcpL4Protocol::CreateSocket |
( |
void |
|
) |
|
- Returns:
- A smart Socket pointer to a TcpSocketImpl, allocated by this instance of the TCP protocol
virtual void ns3::TcpL4Protocol::DoDispose |
( |
void |
|
) |
[protected, virtual] |
This method is called by Object::Dispose or by the object's destructor, whichever comes first.
Subclasses are expected to implement their real destruction code in an overriden version of this method and chain up to their parent's implementation once they are done. i.e., for simplicity, the destructor of every subclass should be empty and its content should be moved to the associated DoDispose method.
It is safe to call GetObject from within this method.
Reimplemented from ns3::Object.
virtual int ns3::TcpL4Protocol::GetProtocolNumber |
( |
void |
|
) |
const [virtual] |
static TypeId ns3::TcpL4Protocol::GetTypeId |
( |
void |
|
) |
[static] |
This method returns the TypeId associated to ns3::TcpL4Protocol.
This object is accessible through the following paths with Config::Set and Config::Connect:
-
/NodeList/[i]/DeviceList/[i]/$ns3::AlohaNoackNetDevice/Phy/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::AlohaNoackNetDevice/Phy/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::BaseStationNetDevice/BsIpcsPacketClassifier/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::BaseStationNetDevice/BsIpcsPacketClassifier/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::BaseStationNetDevice/LinkManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::BaseStationNetDevice/LinkManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::BaseStationNetDevice/SSManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::BaseStationNetDevice/SSManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::BaseStationNetDevice/ServiceFlowManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::BaseStationNetDevice/ServiceFlowManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::NonCommunicatingNetDevice/Phy/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::NonCommunicatingNetDevice/Phy/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::SubscriberStationNetDevice/Classifier/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::SubscriberStationNetDevice/Classifier/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::SubscriberStationNetDevice/LinkManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::SubscriberStationNetDevice/LinkManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::SubscriberStationNetDevice/SSScheduler/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::SubscriberStationNetDevice/SSScheduler/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Channel/NoiseModel/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Channel/NoiseModel/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Channel/PropagationModel/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Channel/PropagationModel/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Mac/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Mac/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Phy/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Phy/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Transducer/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::UanNetDevice/Transducer/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::BaseStationNetDevice/BsIpcsPacketClassifier/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::BaseStationNetDevice/BsIpcsPacketClassifier/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::BaseStationNetDevice/LinkManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::BaseStationNetDevice/LinkManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::BaseStationNetDevice/SSManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::BaseStationNetDevice/SSManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::BaseStationNetDevice/ServiceFlowManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::BaseStationNetDevice/ServiceFlowManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::SubscriberStationNetDevice/Classifier/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::SubscriberStationNetDevice/Classifier/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::SubscriberStationNetDevice/LinkManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::SubscriberStationNetDevice/LinkManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::SubscriberStationNetDevice/SSScheduler/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/$ns3::SubscriberStationNetDevice/SSScheduler/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/BandwidthManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/BandwidthManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/BurstProfileManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/BurstProfileManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/Channel/$ns3::UanChannel/NoiseModel/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/Channel/$ns3::UanChannel/NoiseModel/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/Channel/$ns3::UanChannel/PropagationModel/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/Channel/$ns3::UanChannel/PropagationModel/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/ConnectionManager/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/ConnectionManager/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/Phy/Channel/$ns3::UanChannel/NoiseModel/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/Phy/Channel/$ns3::UanChannel/NoiseModel/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/Phy/Channel/$ns3::UanChannel/PropagationModel/$ns3::Ipv4L4Protocol/$ns3::TcpL4Protocol
-
/NodeList/[i]/DeviceList/[i]/$ns3::WimaxNetDevice/Phy/Channel/$ns3::UanChannel/PropagationModel/$ns3::TcpL4Protocol
Attributes defined for this type:
-
RttEstimatorFactory: How RttEstimator objects are created.
-
SocketList: The list of sockets associated to this protocol.
Attributes defined in parent class ns3::Ipv4L4Protocol:
-
ProtocolNumber: The Ipv4 protocol number.
No TraceSources defined for this type.
Reimplemented from ns3::Ipv4L4Protocol.
virtual void ns3::TcpL4Protocol::NotifyNewAggregate |
( |
|
) |
[protected, virtual] |
This method is invoked whenever two sets of objects are aggregated together. It is invoked exactly once for each object in both sets. This method can be overriden by subclasses who wish to be notified of aggregation events. These subclasses must chain up to their base class NotifyNewAggregate method. It is safe to call GetObject and AggregateObject from within this method.
Reimplemented from ns3::Object.
Send a packet via TCP.
- Parameters:
-
| packet | The packet to send |
| saddr | The source Ipv4Address |
| daddr | The destination Ipv4Address |
| sport | The source port number |
| dport | The destination port number |
| oif | The output interface bound. Defaults to null (unspecified). |
The documentation for this class was generated from the following files:
- src/internet-stack/tcp-l4-protocol.h
- doc/introspected-doxygen.h
