See 7.3.2.85 of draft 2.07. More...
#include <ie-dot11s-peer-management.h>
Public Types | |
| enum | Subtype { PEER_OPEN = 0, PEER_CONFIRM, PEER_CLOSE } |
Public Member Functions | |
| void | SetPeerOpen (uint16_t localLinkId) |
| void | SetPeerClose (uint16_t localLinkID, uint16_t peerLinkId, PmpReasonCode reasonCode) |
| void | SetPeerConfirm (uint16_t localLinkID, uint16_t peerLinkId) |
| PmpReasonCode | GetReasonCode () const |
| uint16_t | GetLocalLinkId () const |
| uint16_t | GetPeerLinkId () const |
| bool | SubtypeIsOpen () const |
| bool | SubtypeIsClose () const |
| bool | SubtypeIsConfirm () const |
| uint8_t | GetSubtype () const |
Inherited from WifiInformationElement | |
| virtual WifiInformationElementId | ElementId () const |
| Own unique Element ID. | |
| virtual uint8_t | GetInformationFieldSize (void) const |
| virtual void | SerializeInformationField (Buffer::Iterator i) const |
| virtual uint8_t | DeserializeInformationField (Buffer::Iterator i, uint8_t length) |
| virtual void | Print (std::ostream &os) const |
| In addition, a subclass may optionally override the following... | |
Friends | |
| bool | operator== (const IePeerManagement &a, const IePeerManagement &b) |
Detailed Description
See 7.3.2.85 of draft 2.07.
Member Function Documentation
| virtual uint8_t ns3::dot11s::IePeerManagement::DeserializeInformationField | ( | Buffer::Iterator | start, | |
| uint8_t | length | |||
| ) | [virtual] |
Deserialize information (i.e., the body of the IE, not including the Element ID and length octets)
Implements ns3::WifiInformationElement.
| virtual uint8_t ns3::dot11s::IePeerManagement::GetInformationFieldSize | ( | void | ) | const [virtual] |
Length of serialized information (i.e., the length of the body of the IE, not including the Element ID and length octets. This is the value that will appear in the second octet of the entire IE - the length field)
Implements ns3::WifiInformationElement.
| virtual void ns3::dot11s::IePeerManagement::Print | ( | std::ostream & | os | ) | const [virtual] |
In addition, a subclass may optionally override the following...
Generate human-readable form of IE
Reimplemented from ns3::WifiInformationElement.
| virtual void ns3::dot11s::IePeerManagement::SerializeInformationField | ( | Buffer::Iterator | start | ) | const [virtual] |
Serialize information (i.e., the body of the IE, not including the Element ID and length octets)
Implements ns3::WifiInformationElement.
The documentation for this class was generated from the following file:
- src/devices/mesh/dot11s/ie-dot11s-peer-management.h
