Classes | |
| struct | Hello |
| struct | Hna |
| struct | Mid |
| struct | Tc |
Public Types | |
| enum | MessageType { HELLO_MESSAGE = 1, TC_MESSAGE = 2, MID_MESSAGE = 3, HNA_MESSAGE = 4 } |
Public Member Functions | |
| void | SetMessageType (MessageType messageType) |
| MessageType | GetMessageType () const |
| void | SetVTime (Time time) |
| Time | GetVTime () const |
| void | SetOriginatorAddress (Ipv4Address originatorAddress) |
| Ipv4Address | GetOriginatorAddress () const |
| void | SetTimeToLive (uint8_t timeToLive) |
| uint8_t | GetTimeToLive () const |
| void | SetHopCount (uint8_t hopCount) |
| uint8_t | GetHopCount () const |
| void | SetMessageSequenceNumber (uint16_t messageSequenceNumber) |
| uint16_t | GetMessageSequenceNumber () const |
| virtual TypeId | GetInstanceTypeId (void) const |
| virtual void | Print (std::ostream &os) const |
| virtual uint32_t | GetSerializedSize (void) const |
| virtual void | Serialize (Buffer::Iterator start) const |
| virtual uint32_t | Deserialize (Buffer::Iterator start) |
| Mid & | GetMid () |
| Hello & | GetHello () |
| Tc & | GetTc () |
| Hna & | GetHna () |
| const Mid & | GetMid () const |
| const Hello & | GetHello () const |
| const Tc & | GetTc () const |
| const Hna & | GetHna () const |
Static Public Member Functions | |
| static TypeId | GetTypeId (void) |
| This method returns the TypeId associated to ns3::olsr::MessageHeader. | |
Member Function Documentation
| virtual uint32_t ns3::olsr::MessageHeader::Deserialize | ( | Buffer::Iterator | start | ) | [virtual] |
- Parameters:
-
start an iterator which points to where the header should written.
- Returns:
- the number of bytes read.
This method is used by Packet::RemoveHeader to re-create a header from the byte buffer of a packet. The data read is expected to match bit-for-bit the representation of this header in real networks.
Implements ns3::Header.
| virtual TypeId ns3::olsr::MessageHeader::GetInstanceTypeId | ( | void | ) | const [virtual] |
- Returns:
- the TypeId associated to the most-derived type of this instance.
This method is typically implemented by ns3::Object::GetInstanceTypeId but some classes which derive from ns3::ObjectBase directly have to implement it themselves.
Implements ns3::ObjectBase.
| virtual uint32_t ns3::olsr::MessageHeader::GetSerializedSize | ( | void | ) | const [virtual] |
- Returns:
- the expected size of the header.
This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. This method should return the number of bytes which are needed to store the full header data by Serialize.
Implements ns3::Header.
| static TypeId ns3::olsr::MessageHeader::GetTypeId | ( | void | ) | [static] |
This method returns the TypeId associated to ns3::olsr::MessageHeader.
No Attributes defined for this type.
No TraceSources defined for this type.
Reimplemented from ns3::Header.
| virtual void ns3::olsr::MessageHeader::Print | ( | std::ostream & | os | ) | const [virtual] |
- Parameters:
-
os output stream This method is used by Packet::Print to print the content of a trailer as ascii data to a c++ output stream. Although the trailer is free to format its output as it wishes, it is recommended to follow a few rules to integrate with the packet pretty printer: start with flags, small field values located between a pair of parens. Values should be separated by whitespace. Follow the parens with the important fields, separated by whitespace. i.e.: (field1 val1 field2 val2 field3 val3) field4 val4 field5 val5
Implements ns3::Header.
| virtual void ns3::olsr::MessageHeader::Serialize | ( | Buffer::Iterator | start | ) | const [virtual] |
- Parameters:
-
start an iterator which points to where the header should be written.
This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. The data written is expected to match bit-for-bit the representation of this header in a real network.
Implements ns3::Header.
The documentation for this class was generated from the following files:
- src/routing/olsr/olsr-header.h
- doc/introspected-doxygen.h
