ns3::ofi::StatsDumpCallback Struct Reference

Callback for a stats dump request. More...

#include "openflow-interface.h"

Collaboration diagram for ns3::ofi::StatsDumpCallback:

Public Attributes
bool	done
	Whether we are done requesting stats.
ofp_stats_request *	rq
	Current stats request.
Stats *	s
	Handler of the stats request.
void *	state
	Stats request state data.
Ptr< OpenFlowSwitchNetDevice >	swtch
	The switch that we're requesting data from.

Detailed Description

Callback for a stats dump request.

Definition at line 371 of file openflow-interface.h.

Member Data Documentation

done

bool ns3::ofi::StatsDumpCallback::done

Whether we are done requesting stats.

Definition at line 373 of file openflow-interface.h.

Referenced by ns3::OpenFlowSwitchNetDevice::ReceiveStatsRequest(), and ns3::OpenFlowSwitchNetDevice::StatsDump().

rq

ofp_stats_request* ns3::ofi::StatsDumpCallback::rq

Current stats request.

Definition at line 374 of file openflow-interface.h.

Referenced by ns3::OpenFlowSwitchNetDevice::ReceiveStatsRequest().

s

Stats* ns3::ofi::StatsDumpCallback::s

Handler of the stats request.

Definition at line 375 of file openflow-interface.h.

Referenced by ns3::OpenFlowSwitchNetDevice::ReceiveStatsRequest(), ns3::OpenFlowSwitchNetDevice::StatsDone(), and ns3::OpenFlowSwitchNetDevice::StatsDump().

state

void* ns3::ofi::StatsDumpCallback::state

Stats request state data.

Definition at line 376 of file openflow-interface.h.

Referenced by ns3::OpenFlowSwitchNetDevice::ReceiveStatsRequest(), ns3::OpenFlowSwitchNetDevice::StatsDone(), and ns3::OpenFlowSwitchNetDevice::StatsDump().

swtch

Ptr<OpenFlowSwitchNetDevice> ns3::ofi::StatsDumpCallback::swtch

The switch that we're requesting data from.

Definition at line 377 of file openflow-interface.h.

Referenced by ns3::OpenFlowSwitchNetDevice::ReceiveStatsRequest(), and ns3::ofi::Controller::StartDump().

---

The documentation for this struct was generated from the following file:

• src/openflow/model/openflow-interface.h
