Public Member Functions | |
| DsaRsp (void) | |
| This class implements the DSA-RSP message described by "IEEE Standard for
Local and metropolitan area networks Part 16: Air Interface for Fixed Broadband Wireless Access Systems" 6.3.2.3.11 DSA-RSP message, page 63. | |
| void | SetTransactionId (uint16_t transactionId) |
| uint16_t | GetTransactionId (void) const |
| void | SetConfirmationCode (uint16_t confirmationCode) |
| uint16_t | GetConfirmationCode (void) const |
| void | SetSfid (uint32_t sfid) |
| set the service flow identifier | |
| uint32_t | GetSfid (void) const |
| void | SetCid (Cid cid) |
| set the connection identifier | |
| Cid | GetCid (void) const |
| void | SetServiceFlow (ServiceFlow sf) |
| specify a service flow to be requested by this message | |
| ServiceFlow | GetServiceFlow (void) const |
| std::string | GetName (void) const |
| virtual TypeId | GetInstanceTypeId (void) const |
| void | Print (std::ostream &os) const |
| uint32_t | GetSerializedSize (void) const |
| void | Serialize (Buffer::Iterator start) const |
| uint32_t | Deserialize (Buffer::Iterator start) |
Static Public Member Functions | |
| static TypeId | GetTypeId (void) |
| This method returns the TypeId associated to ns3::DsaRsp. | |
Member Function Documentation
| uint32_t ns3::DsaRsp::Deserialize | ( | Buffer::Iterator | start | ) | [virtual] |
- Parameters:
-
start an iterator which points to where the header should written.
- Returns:
- the number of bytes read.
This method is used by Packet::RemoveHeader to re-create a header from the byte buffer of a packet. The data read is expected to match bit-for-bit the representation of this header in real networks.
Implements ns3::Header.
| Cid ns3::DsaRsp::GetCid | ( | void | ) | const |
- Returns:
- the connection identifier
| virtual TypeId ns3::DsaRsp::GetInstanceTypeId | ( | void | ) | const [virtual] |
- Returns:
- the TypeId associated to the most-derived type of this instance.
This method is typically implemented by ns3::Object::GetInstanceTypeId but some classes which derive from ns3::ObjectBase directly have to implement it themselves.
Implements ns3::ObjectBase.
| uint32_t ns3::DsaRsp::GetSerializedSize | ( | void | ) | const [virtual] |
- Returns:
- the expected size of the header.
This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. This method should return the number of bytes which are needed to store the full header data by Serialize.
Implements ns3::Header.
| ServiceFlow ns3::DsaRsp::GetServiceFlow | ( | void | ) | const |
- Returns:
- the service flow requested by this message
| uint32_t ns3::DsaRsp::GetSfid | ( | void | ) | const |
- Returns:
- the service flow identifier
| static TypeId ns3::DsaRsp::GetTypeId | ( | void | ) | [static] |
This method returns the TypeId associated to ns3::DsaRsp.
No Attributes defined for this type.
No TraceSources defined for this type.
Reimplemented from ns3::Header.
| void ns3::DsaRsp::Print | ( | std::ostream & | os | ) | const [virtual] |
- Parameters:
-
os output stream This method is used by Packet::Print to print the content of a trailer as ascii data to a c++ output stream. Although the trailer is free to format its output as it wishes, it is recommended to follow a few rules to integrate with the packet pretty printer: start with flags, small field values located between a pair of parens. Values should be separated by whitespace. Follow the parens with the important fields, separated by whitespace. i.e.: (field1 val1 field2 val2 field3 val3) field4 val4 field5 val5
Implements ns3::Header.
| void ns3::DsaRsp::Serialize | ( | Buffer::Iterator | start | ) | const [virtual] |
- Parameters:
-
start an iterator which points to where the header should be written.
This method is used by Packet::AddHeader to store a header into the byte buffer of a packet. The data written is expected to match bit-for-bit the representation of this header in a real network.
Implements ns3::Header.
| void ns3::DsaRsp::SetCid | ( | Cid | cid | ) |
set the connection identifier
- Parameters:
-
cid the connection identifier
| void ns3::DsaRsp::SetServiceFlow | ( | ServiceFlow | sf | ) |
specify a service flow to be requested by this message
- Parameters:
-
sf the service flow
| void ns3::DsaRsp::SetSfid | ( | uint32_t | sfid | ) |
set the service flow identifier
- Parameters:
-
sfid the service flow identifier
The documentation for this class was generated from the following files:
- src/devices/wimax/mac-messages.h
- doc/introspected-doxygen.h
