ns3::PbbAddressTlv Class Reference

An Address TLV. More...

#include <packetbb.h>

Inheritance diagram for ns3::PbbAddressTlv:

Collaboration diagram for ns3::PbbAddressTlv:

List of all members.

Public Member Functions
void	SetIndexStart (uint8_t index)
	Sets the index of the first address in the associated address block that this address TLV applies to.
uint8_t	GetIndexStart (void) const
bool	HasIndexStart (void) const
	Tests whether or not this address TLV has a start index.
void	SetIndexStop (uint8_t index)
	Sets the index of the last address in the associated address block that this address TLV applies to.
uint8_t	GetIndexStop (void) const
bool	HasIndexStop (void) const
	Tests whether or not this address TLV has a stop index.
void	SetMultivalue (bool isMultivalue)
	Sets whether or not this address TLV is "multivalue".
bool	IsMultivalue (void) const
	Tests whether or not this address TLV is "multivalue".

---

Detailed Description

An Address TLV.

---

Member Function Documentation

uint8_t ns3::PbbAddressTlv::GetIndexStart

(

void

)

const

Returns:

the first (inclusive) index of the address in the corresponding address block that this TLV applies to.

Calling this while HasIndexStart is False is undefined. Make sure you check it first. This will be checked by an assert in debug builds.

Reimplemented from ns3::PbbTlv.

uint8_t ns3::PbbAddressTlv::GetIndexStop

(

void

)

const

Returns:

the last (inclusive) index of the address in the corresponding PbbAddressBlock that this TLV applies to.

Calling this while HasIndexStop is False is undefined. Make sure you check it first. This will be checked by an assert in debug builds.

Reimplemented from ns3::PbbTlv.

bool ns3::PbbAddressTlv::HasIndexStart

(

void

)

const

Tests whether or not this address TLV has a start index.

Returns:

true if this address TLV has a start index, false otherwise.

This should be called before calling GetIndexStart to make sure there actually is one.

Reimplemented from ns3::PbbTlv.

bool ns3::PbbAddressTlv::HasIndexStop

(

void

)

const

Tests whether or not this address TLV has a stop index.

Returns:

true if this address TLV has a stop index, false otherwise.

This should be called before calling GetIndexStop to make sure there actually is one.

Reimplemented from ns3::PbbTlv.

bool ns3::PbbAddressTlv::IsMultivalue

(

void

)

const

Tests whether or not this address TLV is "multivalue".

Returns:

whether this address TLV is multivalue or not.

Reimplemented from ns3::PbbTlv.

void ns3::PbbAddressTlv::SetIndexStart

(

uint8_t

index

)

Sets the index of the first address in the associated address block that this address TLV applies to.

Parameters:

index

the index of the first address.

Reimplemented from ns3::PbbTlv.

void ns3::PbbAddressTlv::SetIndexStop

(

uint8_t

index

)

Sets the index of the last address in the associated address block that this address TLV applies to.

Parameters:

index

the index of the last address.

Reimplemented from ns3::PbbTlv.

void ns3::PbbAddressTlv::SetMultivalue

(

bool

isMultivalue

)

Sets whether or not this address TLV is "multivalue".

Parameters:

isMultivalue

whether or not this address TLV should be multivalue.

If true, this means the value associated with this TLV should be divided evenly into (GetIndexStop() - GetIndexStart() + 1) values. Otherwise, the value is one single value that applies to each address in the range.

Reimplemented from ns3::PbbTlv.

---

The documentation for this class was generated from the following file:

• src/node/packetbb.h
