This class is used internally by ConfigStore and GtkConfigStore. More...

#include <attribute-iterator.h>

Inheritance diagram for ns3::AttributeIterator:

Collaboration diagram for ns3::AttributeIterator:

Public Member Functions
	AttributeIterator ()

virtual	~AttributeIterator ()

void	Iterate (void)

Protected Member Functions
std::string	GetCurrentPath (void) const

Private Member Functions
virtual void	DoEndVisitArrayAttribute (void)

virtual void	DoEndVisitArrayItem (void)

virtual void	DoEndVisitObject (void)

virtual void	DoEndVisitPointerAttribute (void)

void	DoIterate (Ptr< Object > object)

virtual void	DoStartVisitArrayAttribute (Ptr< Object > object, std::string name, const ObjectPtrContainerValue &vector)

virtual void	DoStartVisitArrayItem (const ObjectPtrContainerValue &vector, uint32_t index, Ptr< Object > item)

virtual void	DoStartVisitObject (Ptr< Object > object)

virtual void	DoStartVisitPointerAttribute (Ptr< Object > object, std::string name, Ptr< Object > value)

virtual void	DoVisitAttribute (Ptr< Object > object, std::string name)=0

void	EndVisitArrayAttribute (void)

void	EndVisitArrayItem (void)

void	EndVisitObject (void)

void	EndVisitPointerAttribute (void)

std::string	GetCurrentPath (std::string attr) const

bool	IsExamined (Ptr< const Object > object)

void	StartVisitArrayAttribute (Ptr< Object > object, std::string name, const ObjectPtrContainerValue &vector)

void	StartVisitArrayItem (const ObjectPtrContainerValue &vector, uint32_t index, Ptr< Object > item)

void	StartVisitObject (Ptr< Object > object)

void	StartVisitPointerAttribute (Ptr< Object > object, std::string name, Ptr< Object > value)

void	VisitAttribute (Ptr< Object > object, std::string name)

Private Attributes
std::vector< std::string >	m_currentPath

std::vector< Ptr< Object > >	m_examined

Detailed Description

This class is used internally by ConfigStore and GtkConfigStore.

Definition at line 34 of file attribute-iterator.h.

Constructor & Destructor Documentation

ns3::AttributeIterator::AttributeIterator ( )

Definition at line 33 of file attribute-iterator.cc.

ns3::AttributeIterator::~AttributeIterator ( )

virtual

Definition at line 37 of file attribute-iterator.cc.

Member Function Documentation

void ns3::AttributeIterator::DoEndVisitArrayAttribute ( void )

privatevirtual

Reimplemented in ns3::ModelCreator.

Definition at line 116 of file attribute-iterator.cc.

Referenced by EndVisitArrayAttribute().

Here is the caller graph for this function:

void ns3::AttributeIterator::DoEndVisitArrayItem ( void )

privatevirtual

Reimplemented in ns3::ModelCreator.

Definition at line 124 of file attribute-iterator.cc.

Referenced by EndVisitArrayItem().

Here is the caller graph for this function:

void ns3::AttributeIterator::DoEndVisitObject ( void )

privatevirtual

Reimplemented in ns3::ModelCreator.

Definition at line 100 of file attribute-iterator.cc.

Referenced by EndVisitObject().

Here is the caller graph for this function:

void ns3::AttributeIterator::DoEndVisitPointerAttribute ( void )

privatevirtual

Reimplemented in ns3::ModelCreator.

Definition at line 108 of file attribute-iterator.cc.

Referenced by EndVisitPointerAttribute().

Here is the caller graph for this function:

void ns3::AttributeIterator::DoIterate ( Ptr< Object > object )

private

Definition at line 194 of file attribute-iterator.cc.

References ns3::TypeId::AttributeInformation::accessor, ns3::TypeId::ATTR_GET, ns3::TypeId::ATTR_SET, ns3::ObjectPtrContainerValue::Begin(), ns3::TypeId::AttributeInformation::checker, ns3::ObjectPtrContainerValue::End(), EndVisitArrayAttribute(), EndVisitArrayItem(), EndVisitObject(), EndVisitPointerAttribute(), ns3::TypeId::AttributeInformation::flags, ns3::PointerValue::Get(), ns3::TypeId::GetAttribute(), ns3::TypeId::GetAttributeN(), ns3::Object::GetInstanceTypeId(), ns3::TypeId::GetName(), ns3::TypeId::GetParent(), ns3::Object::AggregateIterator::HasNext(), ns3::TypeId::HasParent(), IsExamined(), m_examined, ns3::TypeId::AttributeInformation::name, ns3::Object::AggregateIterator::Next(), NS_LOG_DEBUG, ns3::PeekPointer(), StartVisitArrayAttribute(), StartVisitArrayItem(), StartVisitObject(), StartVisitPointerAttribute(), and VisitAttribute().

Referenced by Iterate().

Here is the call graph for this function:

Here is the caller graph for this function:

void ns3::AttributeIterator::DoStartVisitArrayAttribute	(	Ptr< Object >	object,
		std::string	name,
		const ObjectPtrContainerValue &	vector
	)

privatevirtual

Reimplemented in ns3::ModelCreator.

Definition at line 112 of file attribute-iterator.cc.

Referenced by StartVisitArrayAttribute().

Here is the caller graph for this function:

void ns3::AttributeIterator::DoStartVisitArrayItem	(	const ObjectPtrContainerValue &	vector,
		uint32_t	index,
		Ptr< Object >	item
	)

privatevirtual

Reimplemented in ns3::ModelCreator.

Definition at line 120 of file attribute-iterator.cc.

Referenced by StartVisitArrayItem().

Here is the caller graph for this function:

void ns3::AttributeIterator::DoStartVisitObject ( Ptr< Object > object )

privatevirtual

Reimplemented in ns3::ModelCreator.

Definition at line 96 of file attribute-iterator.cc.

Referenced by StartVisitObject().

Here is the caller graph for this function:

void ns3::AttributeIterator::DoStartVisitPointerAttribute	(	Ptr< Object >	object,
		std::string	name,
		Ptr< Object >	value
	)

privatevirtual

Reimplemented in ns3::ModelCreator.

Definition at line 104 of file attribute-iterator.cc.

Referenced by StartVisitPointerAttribute().

Here is the caller graph for this function:

virtual void ns3::AttributeIterator::DoVisitAttribute	(	Ptr< Object >	object,
		std::string	name
	)

privatepure virtual

Implemented in ns3::ModelCreator.

Referenced by VisitAttribute().

Here is the caller graph for this function:

void ns3::AttributeIterator::EndVisitArrayAttribute ( void )

private

Definition at line 169 of file attribute-iterator.cc.

References DoEndVisitArrayAttribute(), and m_currentPath.

Referenced by DoIterate().

Here is the call graph for this function:

Here is the caller graph for this function:

void ns3::AttributeIterator::EndVisitArrayItem ( void )

private

Definition at line 185 of file attribute-iterator.cc.

References DoEndVisitArrayItem(), and m_currentPath.

Referenced by DoIterate().

Here is the call graph for this function:

Here is the caller graph for this function:

void ns3::AttributeIterator::EndVisitObject ( void )

private

Definition at line 143 of file attribute-iterator.cc.

References DoEndVisitObject(), and m_currentPath.

Referenced by DoIterate(), and Iterate().

Here is the call graph for this function:

Here is the caller graph for this function:

void ns3::AttributeIterator::EndVisitPointerAttribute ( void )

private

Definition at line 156 of file attribute-iterator.cc.

References DoEndVisitPointerAttribute(), and m_currentPath.

Referenced by DoIterate().

Here is the call graph for this function:

Here is the caller graph for this function:

std::string ns3::AttributeIterator::GetCurrentPath ( void ) const

protected

Definition at line 85 of file attribute-iterator.cc.

References m_currentPath.

std::string ns3::AttributeIterator::GetCurrentPath ( std::string attr ) const

private

Definition at line 70 of file attribute-iterator.cc.

References m_currentPath.

bool ns3::AttributeIterator::IsExamined ( Ptr< const Object > object )

private

Definition at line 56 of file attribute-iterator.cc.

References m_examined.

Referenced by DoIterate().

Here is the caller graph for this function:

void ns3::AttributeIterator::Iterate ( void )

Definition at line 42 of file attribute-iterator.cc.

References DoIterate(), EndVisitObject(), ns3::Config::GetRootNamespaceObject(), ns3::Config::GetRootNamespaceObjectN(), m_currentPath, m_examined, NS_ASSERT, and StartVisitObject().

Referenced by ns3::ModelCreator::Build().

Here is the call graph for this function:

Here is the caller graph for this function:

void ns3::AttributeIterator::StartVisitArrayAttribute	(	Ptr< Object >	object,
		std::string	name,
		const ObjectPtrContainerValue &	vector
	)

private

Definition at line 163 of file attribute-iterator.cc.

References DoStartVisitArrayAttribute(), and m_currentPath.

Referenced by DoIterate().

Here is the call graph for this function:

Here is the caller graph for this function:

void ns3::AttributeIterator::StartVisitArrayItem	(	const ObjectPtrContainerValue &	vector,
		uint32_t	index,
		Ptr< Object >	item
	)

private

Definition at line 176 of file attribute-iterator.cc.

References DoStartVisitArrayItem(), ns3::Object::GetInstanceTypeId(), ns3::TypeId::GetName(), and m_currentPath.

Referenced by DoIterate().

Here is the call graph for this function:

Here is the caller graph for this function:

void ns3::AttributeIterator::StartVisitObject ( Ptr< Object > object )

private

Definition at line 137 of file attribute-iterator.cc.

References DoStartVisitObject(), ns3::Object::GetInstanceTypeId(), ns3::TypeId::GetName(), and m_currentPath.

Referenced by DoIterate(), and Iterate().

Here is the call graph for this function:

Here is the caller graph for this function:

void ns3::AttributeIterator::StartVisitPointerAttribute	(	Ptr< Object >	object,
		std::string	name,
		Ptr< Object >	value
	)

private

Definition at line 149 of file attribute-iterator.cc.

References DoStartVisitPointerAttribute(), ns3::Object::GetInstanceTypeId(), ns3::TypeId::GetName(), and m_currentPath.

Referenced by DoIterate().

Here is the call graph for this function:

Here is the caller graph for this function:

void ns3::AttributeIterator::VisitAttribute	(	Ptr< Object >	object,
		std::string	name
	)

private

Definition at line 129 of file attribute-iterator.cc.

References DoVisitAttribute(), and m_currentPath.

Referenced by DoIterate().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

std::vector<std::string> ns3::AttributeIterator::m_currentPath

private

Definition at line 70 of file attribute-iterator.h.

Referenced by EndVisitArrayAttribute(), EndVisitArrayItem(), EndVisitObject(), EndVisitPointerAttribute(), GetCurrentPath(), Iterate(), StartVisitArrayAttribute(), StartVisitArrayItem(), StartVisitObject(), StartVisitPointerAttribute(), and VisitAttribute().

std::vector<Ptr<Object> > ns3::AttributeIterator::m_examined

private

Definition at line 69 of file attribute-iterator.h.

Referenced by DoIterate(), IsExamined(), and Iterate().

The documentation for this class was generated from the following files:

src/config-store/model/attribute-iterator.h
src/config-store/model/attribute-iterator.cc
