Demonstration of a Drop controller. More...
#include <openflow-interface.h>
Public Member Functions | |
void | ReceiveFromSwitch (Ptr< OpenFlowSwitchNetDevice > swtch, ofpbuf *buffer) |
A switch calls this method to pass a message on to the Controller. More... | |
![]() | |
virtual | ~Controller () |
virtual void | AddSwitch (Ptr< OpenFlowSwitchNetDevice > swtch) |
Adds a switch to the controller. More... | |
void | StartDump (StatsDumpCallback *cb) |
Starts a callback-based, reliable, possibly multi-message reply to a request made by the controller. More... | |
![]() | |
Object () | |
virtual | ~Object () |
void | AggregateObject (Ptr< Object > other) |
void | Dispose (void) |
Run the DoDispose methods of this object and all the objects aggregated to it. More... | |
AggregateIterator | GetAggregateIterator (void) const |
virtual TypeId | GetInstanceTypeId (void) const |
template<typename T > | |
Ptr< T > | GetObject (void) const |
template<typename T > | |
Ptr< T > | GetObject (TypeId tid) const |
void | Initialize (void) |
This method calls the virtual DoInitialize method on all the objects aggregated to this object. More... | |
![]() | |
SimpleRefCount () | |
Constructor. More... | |
SimpleRefCount (const SimpleRefCount &o) | |
Copy constructor. More... | |
uint32_t | GetReferenceCount (void) const |
Get the reference count of the object. More... | |
SimpleRefCount & | operator= (const SimpleRefCount &o) |
Assignment. More... | |
void | Ref (void) const |
Increment the reference count. More... | |
void | Unref (void) const |
Decrement the reference count. More... | |
![]() | |
virtual | ~ObjectBase () |
Virtual destructor. More... | |
void | GetAttribute (std::string name, AttributeValue &value) const |
bool | GetAttributeFailSafe (std::string name, AttributeValue &attribute) const |
void | SetAttribute (std::string name, const AttributeValue &value) |
bool | SetAttributeFailSafe (std::string name, const AttributeValue &value) |
bool | TraceConnect (std::string name, std::string context, const CallbackBase &cb) |
bool | TraceConnectWithoutContext (std::string name, const CallbackBase &cb) |
bool | TraceDisconnect (std::string name, std::string context, const CallbackBase &cb) |
bool | TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb) |
Additional Inherited Members | |
![]() | |
static TypeId | GetTypeId (void) |
![]() | |
static TypeId | GetTypeId (void) |
Register this type. More... | |
![]() | |
static void | Cleanup (void) |
Noop. More... | |
![]() | |
static TypeId | GetTypeId (void) |
Get the type ID. More... | |
![]() | |
typedef std::set< Ptr < OpenFlowSwitchNetDevice > > | Switches_t |
![]() | |
ofp_flow_mod * | BuildFlow (sw_flow_key key, uint32_t buffer_id, uint16_t command, void *acts, size_t actions_len, int idle_timeout, int hard_timeout) |
uint8_t | GetPacketType (ofpbuf *buffer) |
virtual void | SendToSwitch (Ptr< OpenFlowSwitchNetDevice > swtch, void *msg, size_t length) |
![]() | |
Object (const Object &o) | |
virtual void | DoDispose (void) |
This method is called by Object::Dispose or by the object's destructor, whichever comes first. More... | |
virtual void | DoInitialize (void) |
This method is called only once by Object::Initialize. More... | |
virtual void | NotifyNewAggregate (void) |
This method is invoked whenever two sets of objects are aggregated together. More... | |
![]() | |
void | ConstructSelf (const AttributeConstructionList &attributes) |
virtual void | NotifyConstructionCompleted (void) |
This method is invoked once all member attributes have been initialized. More... | |
![]() | |
Switches_t | m_switches |
The collection of switches registered to this controller. More... | |
Demonstration of a Drop controller.
When a connected switch passes it a packet the switch doesn't recognize, the controller configures the switch to make a flow that drops alike packets.
Definition at line 449 of file openflow-interface.h.
|
virtual |
A switch calls this method to pass a message on to the Controller.
swtch | The switch the message was received from. |
buffer | The message. |
Reimplemented from ns3::ofi::Controller.
