Doxygen introspection did not find any typical Config paths. More...
#include <ipv6-extension.h>
Public Member Functions | |
Ipv6ExtensionDestination () | |
Constructor. More... | |
~Ipv6ExtensionDestination () | |
Destructor. More... | |
virtual uint8_t | GetExtensionNumber () const |
Get the extension number. More... | |
virtual uint8_t | Process (Ptr< Packet > &packet, uint8_t offset, Ipv6Header const &ipv6Header, Ipv6Address dst, uint8_t *nextHeader, bool &isDropped) |
Process method Called from Ipv6L3Protocol::Receive. More... | |
![]() | |
Ipv6Extension () | |
Constructor. More... | |
virtual | ~Ipv6Extension () |
Destructor. More... | |
int64_t | AssignStreams (int64_t stream) |
Assign a fixed random variable stream number to the random variables used by this model. More... | |
Ptr< Node > | GetNode () const |
Get the node. More... | |
virtual uint8_t | ProcessOptions (Ptr< Packet > &packet, uint8_t offset, uint8_t length, Ipv6Header const &ipv6Header, Ipv6Address dst, uint8_t *nextHeader, bool &isDropped) |
Process options Called by implementing classes to process the options. More... | |
void | SetNode (Ptr< Node > node) |
Set the node. More... | |
![]() | |
Object () | |
virtual | ~Object () |
void | AggregateObject (Ptr< Object > other) |
void | Dispose (void) |
Run the DoDispose methods of this object and all the objects aggregated to it. More... | |
AggregateIterator | GetAggregateIterator (void) const |
virtual TypeId | GetInstanceTypeId (void) const |
template<typename T > | |
Ptr< T > | GetObject (void) const |
template<typename T > | |
Ptr< T > | GetObject (TypeId tid) const |
void | Initialize (void) |
This method calls the virtual DoInitialize method on all the objects aggregated to this object. More... | |
![]() | |
SimpleRefCount () | |
Constructor. More... | |
SimpleRefCount (const SimpleRefCount &o) | |
Copy constructor. More... | |
uint32_t | GetReferenceCount (void) const |
Get the reference count of the object. More... | |
SimpleRefCount & | operator= (const SimpleRefCount &o) |
Assignment. More... | |
void | Ref (void) const |
Increment the reference count. More... | |
void | Unref (void) const |
Decrement the reference count. More... | |
![]() | |
virtual | ~ObjectBase () |
Virtual destructor. More... | |
void | GetAttribute (std::string name, AttributeValue &value) const |
bool | GetAttributeFailSafe (std::string name, AttributeValue &attribute) const |
void | SetAttribute (std::string name, const AttributeValue &value) |
bool | SetAttributeFailSafe (std::string name, const AttributeValue &value) |
bool | TraceConnect (std::string name, std::string context, const CallbackBase &cb) |
bool | TraceConnectWithoutContext (std::string name, const CallbackBase &cb) |
bool | TraceDisconnect (std::string name, std::string context, const CallbackBase &cb) |
bool | TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb) |
Static Public Member Functions | |
static TypeId | GetTypeId () |
Get the type identificator. More... | |
![]() | |
static TypeId | GetTypeId () |
Get the type identificator. More... | |
![]() | |
static TypeId | GetTypeId (void) |
Register this type. More... | |
![]() | |
static void | Cleanup (void) |
Noop. More... | |
![]() | |
static TypeId | GetTypeId (void) |
Get the type ID. More... | |
Static Public Attributes | |
static const uint8_t | EXT_NUMBER = 60 |
Destination extension number. More... | |
Additional Inherited Members | |
![]() | |
Object (const Object &o) | |
virtual void | DoDispose (void) |
This method is called by Object::Dispose or by the object's destructor, whichever comes first. More... | |
virtual void | DoInitialize (void) |
This method is called only once by Object::Initialize. More... | |
virtual void | NotifyNewAggregate (void) |
This method is invoked whenever two sets of objects are aggregated together. More... | |
![]() | |
void | ConstructSelf (const AttributeConstructionList &attributes) |
virtual void | NotifyConstructionCompleted (void) |
This method is invoked once all member attributes have been initialized. More... | |
![]() | |
TracedCallback< Ptr< const Packet > > | m_dropTrace |
Drop trace callback. More... | |
Ptr< UniformRandomVariable > | m_uvar |
Provides uniform random variables. More... | |
Doxygen introspection did not find any typical Config paths.
IPv6 Extension Destination.
No Attributes are defined for this type.
No TraceSources are defined for this type.
Definition at line 193 of file ipv6-extension.h.
ns3::Ipv6ExtensionDestination::Ipv6ExtensionDestination | ( | ) |
ns3::Ipv6ExtensionDestination::~Ipv6ExtensionDestination | ( | ) |
|
virtual |
Get the extension number.
Implements ns3::Ipv6Extension.
Definition at line 261 of file ipv6-extension.cc.
References EXT_NUMBER, and NS_LOG_FUNCTION_NOARGS.
|
static |
Get the type identificator.
Definition at line 242 of file ipv6-extension.cc.
References ns3::TypeId::SetParent().
|
virtual |
Process method Called from Ipv6L3Protocol::Receive.
packet | the packet |
offset | the offset of the extension to process |
ipv6Header | the IPv6 header of packet received |
dst | destination address of the packet received (i.e. us) |
nextHeader | the next header |
isDropped | if the packet must be dropped |
Implements ns3::Ipv6Extension.
Definition at line 268 of file ipv6-extension.cc.
References ns3::Packet::Copy(), ns3::Ipv6ExtensionHeader::GetLength(), ns3::Ipv6ExtensionHeader::GetNextHeader(), ns3::OptionField::GetOptionsOffset(), NS_LOG_FUNCTION, ns3::Ipv6Extension::ProcessOptions(), ns3::Packet::RemoveAtStart(), and ns3::Packet::RemoveHeader().
|
static |
Destination extension number.
Definition at line 199 of file ipv6-extension.h.
Referenced by GetExtensionNumber().
